Danfoss VMT Motorized Control-Valve Body 2-Way, DN 15, PN 10, Kvs 2.8

Danfoss VMT (globe valves), OEM order code 003L3520. Seated motorized control-valve body for modulating flow control in heating and cooling systems, driven by a separate thermal or electric actuator. Manufacturer description: VMT PN10 15/2,8 2-way/2 ext.thr size.Flat. connection/size DN 15, Kvs 2.8 m³/h, PN 10; max. differential pressure 0.8 bar, media/setting temperature 2 °C to 120 °C, body material Brass W. No 2.0402. EAN 5702425080715. HS 8481.80. Specifications quoted verbatim from store.danfoss.com (code 003L3520).

Brand

Danfoss Part number: 003L3520 Code number: 003L3520 Type: VMT Product group: Motorized control valves Description: VMT PN10 15/2,8 2-way/2 ext.thr size.Flat Gross weight: 0.368 Kilogram Net weight: 0.368 Kilogram Application: Heating and cooling Cavitation factor: 0.5 Connection size: G 3/4 A Connection standard: ISO 228/1 Connection types: External Thread Diameter [mm]: 15 mm Differential pressure range [bar] [Max]: 0.8 bar Flow characteristic: Linear Function: Control valve Kvs values [m³/h]: 2.8 m³/h Media pH [Max]: 10 Media pH [Min]: 7 Media temperature [°C] [Max]: 120 °C Media temperature [°C] [Min]: 2 °C Medium alternative: Glycolic water up to 30% Mounting version: Free Number of ports: 2 Permissible media: District heating/cooling circulation water Pressure class: PN 10 Pressure nominal [bar]: 10 bar Spindle position: Normally open Valve body material: Brass W. No 2.0402 Valve cone material: NBR rubber Valve size: DN 15 EAN: 5702425080715 HS code: 8481.80 (taps, cocks, valves for pipes)

Size / Series

DN 15

Material

Brass W. No 2.0402

Pressure Rating

PN 10; max. differential pressure 0.8 bar

Temperature Range

2 °C to 120 °C

HS Code

8481.80
