Danfoss VL2 PN6 DN50/40 flange

Danfoss VL 2 two-way seated flanged control-valve body, OEM order code 065Z0380. VL2 PN6 DN50/40 flange. Nominal size DN 50, Kvs 40 m³/h, nominal pressure PN 6 (6 bar), valve stroke 15 mm. Equal percentage flow characteristic, control ratio 100:1. Body of Grey cast iron EN-GJL-250 (GG-25), cone Brass, stem Stainless steel. For heating and cooling circuits on district heating/cooling circulation water, media temperature -10 °C to 120 °C. The valve body is driven by a matched Danfoss electric actuator (AMV/AME series) sized to the 15 mm valve stroke. Data quoted verbatim from store.danfoss.com (code 065Z0380).

Code number

065Z0380

Type

VL 2

Product group

Other valves

Gross weight

7.2 Kilogram

Net weight

7.07 Kilogram

Volume

11.322 Liter

Application

Heating and cooling

Application alternative VSP

District heating

Connection types

Flange

Control ratio

100:1

Description

VL2 PN6 DN50/40 flange

Diameter [mm]

50 mm

Differential pressure range [bar] [Max]

4 bar

Flow characteristic

Equal percentage

Function

Pressure relief

Kvs values [m³/h]

40 m³/h

Leakage through port max. [% Kvs]

bubble tight design

Media pH [Max]

10

Media pH [Min]

7

Media temperature [°C] [Max]

120 °C

Media temperature [°C] [Min]

-10 °C

Medium alternative

Glycolic water up to 50%

Mounting version

Flow

Number of ports

2

Permissible media

District heating/cooling circulation water

Pressure nominal [bar]

6 bar

Stroke [mm]

15 mm

Stuffing box sealing material

EPDM

Valve body material

Grey cast iron EN-GJL-250 (GG-25)

Valve cone material

Brass

Valve stem material

Stainless steel

EAN

5710104009322

HS code

8481.80 (taps, cocks, valves for pipes)

Size / Series

Accessories

Material

Grey cast iron EN-GJL-250 (GG-25); cone Brass; stem Stainless steel

Pressure Rating

PN 6 (6 bar); max differential pressure 4 bar

Temperature Range

-10 °C to 120 °C

HS Code

8481.80
