Danfoss TWA-K electrothermal actuator, 230 V AC, normally closed

Danfoss TWA-K electrothermal (thermal-wax) valve actuator, OEM order code 088H3142. The TWA-K converts a switching signal from a room thermostat or controller into valve movement on hydronic floor-heating manifolds and radiator/zone valves — no auxiliary air or hydraulics. Normally closed (NC) — the valve is closed when de-energised and opens when the actuator is powered. Supply voltage 230 V AC (50/60 Hz), power consumption 2 W. M 30 x 1.5 threaded connection; fits valve bodies and manifolds with the standard M 30 x 1.5 valve thread. 0.95 m connecting cable. Enclosure rating IP41. Net weight 125 Gram. Genuine Danfoss part; technical data quoted verbatim from store.danfoss.com (code 088H3142). OEM P/N 088H3142, EAN 5702420049649.

Brand

Danfoss

Part number

088H3142

Type

TWA-K

Product group

Thermal actuators

Description

TWA-K NC 230V

Actuator principle

Electrothermal (thermal wax element)

Valve function

NC

End-switch

No

Supply voltage

230 V AC

Frequency range

50 Hz – 60 Hz

Power consumption

2 W

Connection

M 30 x 1.5

Connection type

M 30 x 1.5

Cable length

0.95 m

IP protection class

IP41

REACH candidate-list substances

Lead (CAS no. 7439-92-1)

Net weight

125 Gram

Gross weight

130 Gram

EAN

5702420049649

HS code

8481.90 (parts of taps, cocks, valves and similar appliances)

Material

Polyamide housing

Thread Standard

M 30 x 1.5

IP Rating

IP41

HS Code

8481.90
