Danfoss SVA-S SS 20 straightway shut-off valve, cap, 20 mm (3/4 in) butt weld ASME B 36.19M Schedule 40, stainless steel, 52 bar
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss SVA-S SS 20 straightway shut-off (stop) valve for industrial refrigeration, code 148B5398. Stainless steel body with butt weld connections to ASME B 36.19M Schedule 40, nominal size 20 mm (3/4 in). Operated with a cap; bi-directional (bi-flow) shut-off. Maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F). Flow coefficient Kv 10.2 m3/h (Cv 11.79 gal/min). The SVA-S is the standard-neck stainless shut-off valve in the Danfoss SVL Flexline programme; the renewable seat and cone close tightly and the valve can be dismantled and repaired in line. For HCFC, non-flammable HFC, R717 (ammonia) and R744 (CO2) systems.
Technical Specifications
- Type
- SVA-S SS 20 shut-off valve (SVL Flexline)
- Code number
- 148B5398
- Series
- SVA-S SS
- Direction
- Straightway
- Connection type
- Butt weld
- Connection standard
- ASME B 36.19M Schedule 40
- Nominal size
- 20 mm (3/4 in)
- Top equipment
- Cap
- Body material
- Stainless steel
- Maximum working pressure
- 52 bar (754 psig)
- Media temperature range
- -60 to 150 C (-76 to 302 F)
- Kv value
- 10.2 m3/h (Cv 11.79 gal/min)
- Flow direction
- Bi-flow
- Applicable media
- HCFC, HFC, R717 (ammonia), R744 (CO2)
- PED assessment
- Article 4, paragraph 3 (sound engineering practice)
- EAN
- 5702428990202
- Net weight
- 1.684 Kilogram
- Product group
- Shut-off and regulating valves
- China RoHS compliance
- Yes
- Colour Paint
- Reddish brown
- Connection material
- Stainless steel
- Cv value [gal/min]
- 11.83 gal/min
- Equipment
- Cap
- EU RoHS compliance
- Yes
- Fluid Group
- 1
- Inlet connection size [in]
- 3/4 in
- Inlet connection size [mm]
- 20 mm
- Inlet connection type
- Butt weld
- Kv value [m³/h]
- 10.2 m³/h
- Max. Working Pressure [bar]
- 52 bar
- Max. Working Pressure [psig]
- 754 psig
- Neck
- Standard
- Outlet connection size [in]
- 3/4 in
- Outlet connection size [mm]
- 20 mm
- Outlet connection type
- Butt weld
- PED category
- Art. 4, par. 3
- REACH Candidate List substances
- No
- Refrigerants
- R113
- Temperature range [°C] [max]
- 150 °C
- Temperature range [°C] [min]
- -60 °C
- Temperature range [°F] [max]
- 302 °F
- Temperature range [°F] [min]
- -76 °F
- Valve version
- Standard version
Standards & Compliance
- Standard
- ASME B 36.19M Schedule 40
- Size / Series
- 20 mm
- Material
- Stainless steel
- Pressure Rating
- 52 bar
- Temperature Range
- -60 to 150 C
- HS Code
- 8481.80
Compatibility & Fitment
Danfoss SVL Flexline SVA-S SS stainless shut-off valve. This code is the straightway SVA-S SS 20 with butt weld (ASME B 36.19M Schedule 40) ends and cap. Confirm line size (20 mm (3/4 in)), connection type/standard, direction (straightway) and refrigerant before ordering. EN 10220 and ASME weld-end preparations are not interchangeable — the EN cell of this size is a separate code. Shares the SVL Flexline platform with REG-SA/REG-SB regulating valves, SCA-X/CHV-X check valves and FIA strainers of the same nominal size.
