Danfoss MBT 9110 temperature transmitter, thermocouple Type K input, 4-20 mA output, 0 to +600 C range
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss MBT 9110 temperature transmitter, code 084Z8129 (type designation MBT 9110-005A-E160). Two-wire loop-powered transmitter that converts a thermocouple Type K (NiCr-Ni) input into a linear 4-20 mA output over a factory-set measuring range of 0 to +600 C (+32 to +1112 F). Supply voltage 7.2-35 V DC; 2-wire connection, 2 terminals. IP54 enclosure; Galvanically isolated in box (head-mount) housing. Supplied in a 8-piece multipack. CE marked.
Technical Specifications
- Type
- MBT 9110 (temperature transmitter)
- Type designation
- MBT 9110-005A-E160
- Code number
- 084Z8129
- Sensor input
- thermocouple Type K (NiCr-Ni)
- Measuring range
- 0 to +600 C (+32 to +1112 F)
- Output signal
- 4-20 mA (2-wire, loop powered)
- Supply voltage
- 7.2-35 V DC
- Electrical connection
- 2-wire output, 2 terminals
- Enclosure rating
- IP54
- Transmitter type
- Galvanically isolated in box (head-mount)
- Packing format
- Multi pack (8 pc)
- Approvals
- CE
- EAN
- 5702423098828
- Net weight
- 0.396 Kilogram
- Product group
- Sensors
- Ambient temperature max. [°C]
- 85 °C
- Ambient temperature max. [°F]
- 185 °F
- Approval
- CE
- CE mark
- Yes
- China RoHS compliance
- Out of scope
- EEE category
- 5 small equipment (any external dimension < 50 cm)
- Electrical connection size
- 2 terminals
- Enclosure rating IP
- IP54
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(c)
- In scope of WEEE
- Yes
- Insertion type
- Fixed
- Measuring range [°C] [max]
- 600 °C
- Measuring range [°C] [min]
- 0 °C
- Measuring range [°F] [max]
- 1112 °F
- Measuring range [°F] [min]
- 32 °F
- Number of terminals [pcs]
- 2 pc
- Output signal [mA] [max]
- 20 mA
- Output signal [mA] [min]
- 4 mA
- REACH Candidate List substances
- Lead (CAS no. 7439-92-1)
- Supply voltage [V] DC [max]
- 35 V
- Supply voltage [V] DC [min]
- 7.2 V
- Temperature range [°C] [max]
- 1372 °C
- Temperature range [°C] [min]
- -180 °C
- Temperature range [°F] [max]
- 2502 °F
- Temperature range [°F] [min]
- -292 °F
- Thermocouple
- 1 X NiCr-Ni, Type K
- Transmitter setting range [°C] [max]
- 600 °C
- Transmitter setting range [°C] [min]
- 0 °C
- Transmitter setting range [°F] [max]
- 1112 °F
- Transmitter setting range [°F] [min]
- 32 °F
- Wires [pcs]
- 2 pc
Standards & Compliance
- Temperature Range
- 0 to +600 C
- IP Rating
- IP54
- HS Code
- 9025.19
Compatibility & Fitment
MBT 9110 loop-powered transmitter with a factory-set 0 to +600 C range. Pair with a Type K thermocouple sensor and confirm the range suits the process and the 4-20 mA loop before ordering; range is not field-adjustable.
