Danfoss weld flange set, DN15 (1/2 in), butt weld, ASME B36.10M Schedule 80, steel, 2-flange set (027N2021)
Danfoss · HVAC & Refrigeration · Valve Spare Parts
Danfoss flange set, code 027N2021: a pair of steel weld flanges (2 flanges per set) for connecting Danfoss industrial-refrigeration valves and line components to butt weld pipework. Nominal size DN15 (1/2 in). Flange type butt weld to ASME B36.10M Schedule 80; oval flange form, tongue face, flange version 1.3. Fits: CVK, CVM, EVR 15, EVRA 3-15, NRVA 15-20, TE 12, TEA 20, TEAT 20, TEVA 20. Steel construction for ammonia (R717) and fluorinated-refrigerant service. Supplied as a set of two flanges.
Specifications
- Part number
- 027N2021
- HS code
- 7307.91
- Material
- Steel
- Standard
- ASME B36.10M Schedule 80
- Standard size
- DN15 (1/2 in)
- Thread standard
- Butt weld, ASME B36.10M Schedule 80
Compatibility
Connection set for: CVK, CVM, EVR 15, EVRA 3-15, NRVA 15-20, TE 12, TEA 20, TEAT 20, TEVA 20. Verify valve size, connection standard (ASME B36.10M Schedule 80) and flange face before ordering; supplied as a set of two flanges.
Standards
- ASME B36.10M Schedule 80 (flange connection)
- EU RoHS
- China RoHS
Approvals
