Danfoss weld flange set, DN32 (1 1/4 in), butt weld, ASME B36.10M Schedule 80, steel, 2-flange set (027N2024)
Danfoss · HVAC & Refrigeration · Valve Spare Parts
Danfoss flange set, code 027N2024: a pair of steel weld flanges (2 flanges per set) for connecting Danfoss industrial-refrigeration valves and line components to butt weld pipework. Nominal size DN32 (1 1/4 in). Flange type butt weld to ASME B36.10M Schedule 80; square flange form, tongue face, flange version 4.0. Fits: NRVA 25-32. Steel construction for ammonia (R717) and fluorinated-refrigerant service. Supplied as a set of two flanges.
Specifications
- Part number
- 027N2024
- HS code
- 7307.91
- Material
- Steel
- Standard
- ASME B36.10M Schedule 80
- Standard size
- DN32 (1 1/4 in)
- Thread standard
- Butt weld, ASME B36.10M Schedule 80
Compatibility
Connection set for: NRVA 25-32. Verify valve size, connection standard (ASME B36.10M Schedule 80) and flange face before ordering; supplied as a set of two flanges.
Standards
- ASME B36.10M Schedule 80 (flange connection)
- EU RoHS
- China RoHS
Approvals
