Danfoss weld flange set, DN32 (1 1/4 in), socket weld, ASME B16.11, steel, 2-flange set (027N2003)
Danfoss · HVAC & Refrigeration · Valve Spare Parts
Danfoss flange set, code 027N2003: a pair of steel weld flanges (2 flanges per set) for connecting Danfoss industrial-refrigeration valves and line components to socket weld pipework. Nominal size DN32 (1 1/4 in). Flange type socket weld to ASME B16.11; square flange form, tongue face, flange version 10.0. Fits: PM 32, PMFH 125, PMFL 125, PML 32, PMLX 32. Steel construction for ammonia (R717) and fluorinated-refrigerant service. Supplied as a set of two flanges.
Specifications
- Part number
- 027N2003
- HS code
- 7307.91
- Material
- Steel
- Standard
- ASME B16.11
- Standard size
- DN32 (1 1/4 in)
- Thread standard
- Socket weld, ASME B16.11
Compatibility
Connection set for: PM 32, PMFH 125, PMFL 125, PML 32, PMLX 32. Verify valve size, connection standard (ASME B16.11) and flange face before ordering; supplied as a set of two flanges.
Standards
- ASME B16.11 (flange connection)
- EU RoHS
- China RoHS
Approvals
