Danfoss weld flange set, DN32 (1 1/4 in), butt weld, EN 10220, steel, 2-flange set (027N1230)
Danfoss · HVAC & Refrigeration · Valve Spare Parts
Danfoss flange set, code 027N1230: a pair of steel weld flanges (2 flanges per set) for connecting Danfoss industrial-refrigeration valves and line components to butt weld pipework. Nominal size DN32 (1 1/4 in). Flange type butt weld to EN 10220; oval flange form, tongue face, flange version 3.0. Fits: EVR 20-25, EVRA 20-25, FA 20, PM 5-25, PMC 5-20, PMFH 80, PMFL 80, TEA 85, TEAQ 85, TEAT 85, TEVA 85. Steel construction for ammonia (R717) and fluorinated-refrigerant service. Supplied as a set of two flanges.
Specifications
- Part number
- 027N1230
- HS code
- 7307.91
- Material
- Steel
- Standard
- EN 10220
- Standard size
- DN32 (1 1/4 in)
- Thread standard
- Butt weld, EN 10220
Compatibility
Connection set for: EVR 20-25, EVRA 20-25, FA 20, PM 5-25, PMC 5-20, PMFH 80, PMFL 80, TEA 85, TEAQ 85, TEAT 85, TEVA 85. Verify valve size, connection standard (EN 10220) and flange face before ordering; supplied as a set of two flanges.
Standards
- EN 10220 (flange connection)
- EU RoHS
- China RoHS
Approvals
