Danfoss weld flange set, DN20 (3/4 in), butt weld, ASME B36.10M Schedule 80, steel, 2-Flange set
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss flange set, code 027N2022: a pair of steel weld flanges (2 flanges per set) for connecting Danfoss industrial-refrigeration valves and line components to butt weld pipework. Nominal size DN20 (3/4 in). Flange type butt weld to ASME B36.10M Schedule 80; oval flange form, tongue face, flange version 1.3. Fits: CVK, CVM, EVR 15, EVRA 3-15, NRVA 15-20, TE 12, TEA 20, TEAT 20, TEVA 20. Steel construction for ammonia (R717) and fluorinated-refrigerant service. Supplied as a set of two flanges.
Technical Specifications
- Type
- Weld flange set (2 flanges)
- Code number
- 027N2022
- Nominal size
- DN20 (3/4 in)
- Connection
- Butt weld
- Connection standard
- ASME B36.10M Schedule 80
- Flange form
- Oval, tongue face
- Flange version
- 1.3
- Material
- Steel
- Compatible valves
- CVK, CVM, EVR 15, EVRA 3-15, NRVA 15-20, TE 12, TEA 20, TEAT 20, TEVA 20
- Net weight
- 0.5 kg (gross 0.522 kg)
- Packing
- 16 pc per pack
- EAN
- 5702428196918
- Product group
- Flanges
- China RoHS compliance
- Yes
- Connection Code
- (2002:S80:20)
- Connection size [in]
- 3/4 in
- Connection size [mm]
- 20 mm
- Connection type
- Butt weld
- EU RoHS compliance
- Yes
- Flange design
- Tongue
- Material Spec.
- Steel
- Parts included
- 2 flanges
- REACH Candidate List substances
- No
- Refrigerants
- R717
- Used for product
- CVK
Standards & Compliance
- Standard
- ASME B36.10M Schedule 80
- Size / Series
- DN20 (3/4 in)
- Material
- Steel
- Thread Standard
- Butt weld, ASME B36.10M Schedule 80
- HS Code
- 7307.91
Compatibility & Fitment
Connection set for: CVK, CVM, EVR 15, EVRA 3-15, NRVA 15-20, TE 12, TEA 20, TEAT 20, TEVA 20. Verify valve size, connection standard (ASME B36.10M Schedule 80) and flange face before ordering; supplied as a set of two flanges.
