Danfoss FIA 32 angleway strainer housing, 32 mm (1 1/4 in) socket weld ASME B 16.11, 52 bar, steel (code 148B5546)
Danfoss · HVAC & Refrigeration · Filters & Driers
Danfoss FIA 32 strainer (filter) housing for the SVL Flexline industrial-refrigeration range, store code 148B5546, angleway body. The FIA holds a replaceable strainer insert that protects downstream components from dirt and weld slag during commissioning and operation; the insert is exchanged through a bolted cover. This code is nominal size 32 mm (1 1/4 in) with socket weld connections to ASME B 16.11. Steel housing for R717 (ammonia), R744 (CO2) and fluorinated refrigerants and their oils. Maximum working pressure 52 bar (754 psig); media temperature range -60 to 150 C (-76 to 302 F). With the µ100 plain insert the flow coefficient Kv is about 23 m3/h. The FIA INS strainer insert (38/72/100/150/250/500 micron, plain or pleated) is ordered separately. Specifications per Danfoss store code 148B5546.
Specifications
- Part number
- 148B5546
- HS code
- 8421.39
- Material
- Steel
- Pressure rating
- 52 bar
- Temperature range
- -60 to 150 C
- Standard
- ASME B 16.11
- Standard size
- 32 mm
Compatibility
Danfoss SVL Flexline FIA 32 strainer housing. Pair with a FIA INS strainer insert in the required micron rating (38/72/100/150/250/500, plain or pleated). EN 10220 and ASME weld-end preparations are not interchangeable — confirm the mating pipe schedule before ordering. Shares the SVL Flexline platform with SVA-S/SVA-L shut-off valves and REG regulating valves of the same nominal size.
Standards
- ASME B 16.11
- PED 2014/68/EU
