Danfoss EVRA 3 solenoid valve, DN10 flange, steel body, 42 bar, NC
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss EVRA 3 solenoid valve for industrial and commercial refrigeration, store code 032F6115. NC (normally closed) valve, direct-operated, with DN10 flange connections. Flow coefficient Kv 0.23 m³/h; orifice 3 mm. Maximum working pressure 42 bar (610 psig); media temperature range -40 to 105 °C. Body material: Steel body. Suitable for R717 (ammonia), R502, R134a, R22, R404A, R407A/B/C/F, R410A, R421A and other HFC/HCFC refrigerants. EVRA industrial solenoid valve for ammonia (R717) and HFC/HCFC refrigeration plant; flange connections (flange set ordered separately). Net weight not reliably published on the store page (data anomaly); gross/shipping weight 0.903 kg. Coil ordered separately. C UL US Listed. Weight: gross 0.903 kg. Specifications per Danfoss store code 032F6115.
Technical Specifications
- Type
- EVRA 3 solenoid valve
- Code number
- 032F6115
- Connection
- DN10 flange
- Function
- NC (normally closed)
- Valve operation
- Direct-operated
- Orifice size
- 3 mm
- Flow coefficient
- Kv 0.23 m³/h
- Maximum working pressure
- 42 bar (610 psig)
- Media temperature range
- -40 to 105 °C
- Body material
- Steel body
- Applicable refrigerants
- R717 (ammonia), R502, R134a, R22, R404A, R407A/B/C/F, R410A, R421A and other HFC/HCFC refrigerants
- Weight
- gross 0.903 kg
- Coil
- ordered separately
- Approvals
- UL, EAC
- EAN
- 5702428675017
- Net weight
- 0.002 Kilogram
- Product group
- Solenoid valves accessories
- China RoHS compliance
- Yes
- Direction
- None
- EU RoHS compliance
- Yes
- REACH Candidate List substances
- No
- Type designation
- O-ring
- Used for product
- EVQ 10
Standards & Compliance
- Standard
- Flange
- Size / Series
- DN10
- Material
- Steel body
- Pressure Rating
- 42 bar
- Temperature Range
- -40 to 105 °C
- HS Code
- 8481.80
Compatibility & Fitment
Danfoss EVRA 3 refrigeration solenoid valve. Coil is ordered separately — match coil voltage/frequency and connector to the installation. Refrigerant and pressure compatibility per the Danfoss data sheet; verify against your system specification before ordering.
