Danfoss S Oil nozzle - 3.31KG/h, 0.85US gal/h, 60°, S, red
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss S Oil nozzle. Oil pumps and accessories (Plumbing / Heat / Valves for heating and cooling systems). Principal data: capacity 3.31 kg/h, output per hour 0.85 US gal/h, beam angle 60°, spread pattern S. Supplied under manufacturer part number 030F6918, EAN 5702425017162, HS code 8416.90, country of origin Denmark.
Technical Specifications
- Product type
- Oil pumps and accessories
- Product group
- Heat
- Capacity
- 3.31 kg/h
- Output per hour
- 0.85 US gal/h
- Beam angle
- 60°
- Spread pattern
- S
- Color
- Red
- Material
- Brass
- REACH SVHC substance above 0.1%
- Lead
- Sales unit
- Pack, Ctn. , Plt.
- Carbon footprint (EPD)
- 0.2395 kg CO2e per pcs
- Country of origin
- Denmark
- Customs tariff code (EU CN)
- 84169000
- HS code
- 8416.90
- Manufacturer part number
- 030F6918
- VVS number
- 369251628
- EAN
- 5702425017162
- Net weight
- 0.032 Kilogram
- Type
- OD S
- Capacity [kg/h]
- 3.31 kg/h
- Capacity [KW]
- 0 kW
- Capacity [l/h]
- 0 L/h
- Capacity [USgal/h]
- 0.85 gal/h
- CE mark
- No
- CEN
- Yes
- China RoHS compliance
- Yes
- Description
- 0.85GAL 60S CEN
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(a)-I
- Filter grade [µm]
- 45
- Filter type
- Sintered
- LE anti-drip valve
- No
- Material type
- Brass
- REACH Candidate Strip substances
- Lead (CAS no. 7439-92-1)
- Reference point
- 7 bar, 3.4 cSt, 820 kg/m³
- Shape
- Conical
- Specification point
- 10 bar, 3.4 cSt, 840 kg/m³
- Spray angle [°]
- 60 °
- Spray pattern
- Solid
- spray pattern marking
- S
- UL mark
- No
Standards & Compliance
- HS Code
- 8416.90
Cross References
- MPN 030F6918
- EAN 5702425017162
- VVS 369251628
Product Documentation
More from Danfoss
Danfoss
Danfoss Immersion Tube - 10247980
Danfoss
Danfoss VMT/8 Seat Valve 2-Way - 25, 1 1/4", Nipple, 3.1M³/h
065F0125
Danfoss
Danfoss Coupling Box
10248100
Danfoss
Danfoss AVTA 15 Thermostatic Valve - 25°C, 65°C, 1.9M³/h
10023959
Danfoss
Danfoss MBC 5100 Pressure Switch - 10-100bar
10248377
Danfoss
Danfoss Cable Plug 24V - 9-22 coil AB/AC
042N0267
Danfoss
Danfoss MSV-S Ball Valve with 3/4” drain and connection nipple - 50, coupling/coupling, 2", 40M³/h
10023663
Danfoss
Danfoss MBS 3300 Pressure Transmitter - 1/4", 0-25bar
060G1467
Technical guides
- Cross-Referencing Danfoss Refrigeration Components by IMPA and OEM Code
- Danfoss Product Code Decoder — 003Z, 013G, 017B, 023U, 027L, 032F, 060G, 060H, 065B, 065Z, 068Z, 084H, 132F, 148B Series (Complete Reference)
- Danfoss Maneurop MTZ Reciprocating Compressors — Model Range, Voltage Codes and Replacement Guide
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 030F6918?
- 030F6918 can be ordered from cballast.com as a Danfoss catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Danfoss product?
- The manufacturer part number is 030F6918.
- What is the HS code for 030F6918?
- The customs tariff (HS) code for 030F6918 is 8416.90.
- Who manufactures 030F6918?
- 030F6918 is a Danfoss product in the HVAC & Refrigeration range.
- Is a datasheet available for 030F6918?
- Yes — the 030F6918 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 030F6918?
- The minimum order quantity is 1.
- Is 030F6918 available?
- Yes — 030F6918 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
