Danfoss pressure transmitter MBS 9200, 1/4" — 0/250MBAR, plug, IP65

Danfoss pressure transmitter MBS 9200, 1/4" — 0/250MBAR, plug, IP65. Reference part number 064G5218.

Code number

064G5218

EAN

5702428878821

Net weight

0.161 Kilogram

- common

Pin 2

+ supply

Pin 1

Acc. @ ref. Temp. ±FS typ. [%]

0.50 %

Approval

C UL US UL Recognized; CE

Burst pressure [bar]

50.0 bar

CE mark

Yes

Durability P @ 10-90% FS

10000000

Electrical conn. Male/Female

Male

Electrical connection

Angular connector

Electrical connection size

Pg 9

Electrical connection standard

EN 175301-803-A

Enclosure rating IP

IP65

EU RoHS compliance

Yes with exemptions

Hysteresis and repeat.[±FS%]

0.10 %

Intrinsically safe

No

Mount.pos. err. @ 180°[±FS%]

0.20 %

Non-linearity BFSL [±FS%]

0.20 %

Output signal

Current

Overload pressure max. [bar]

3.5 bar

Pressure connection HEX [mm]

27.0 mm

Pressure connection notes

A

Pressure connection size

1/4

Pressure connection standard

DIN 3852-E

Pressure connection type

G

Pressure Male/Female

Male

Pressure reference

Gauge (relative)

Product group

Sensors

Product line

Sensing Solutions

Product Type

MBS 9200

Pulse-snubber

No

Recommen. mounting torque [Nm]

25 Nm

Reference temperature [°C]

25 °C

Specification key

MBS 9200-B511-A1GB04-2

TEB inside CTR ±FS [%]

1.50 %

UL mark

Yes

Ambient temperature range [°C]

-25 °C … 100 °C

Compensated temp. range [°C]

0 °C … 80 °C

Medium temperature range [°C]

-20 °C … 125 °C

Output signal [mA]

4 mA … 20 mA

Pressure range [mbar]

0.00 mbar … 250.00 mbar

Pressure range [psi]

0.00 psi … 3.63 psi

Storage temperature range [°C]

-40 °C … 125 °C

Supply voltage [V] DC

9.00 V … 32.00 V

Measuring range

0–250 mbar

Process connection

1/4 in

IP rating

IP65

Gross weight

0.164 Kilogram

Volume

0.253 Liter

Type

MBS 9200

Product Name Description

Pressure transmitter

Ambient temperature range [°C] [max]

100 °C

Ambient temperature range [°C] [min]

-25 °C

China RoHS compliance

Out of scope

Compensated temp. range [°C] [max]

80 °C

Compensated temp. range [°C] [min]

0 °C

EEE category

5 small equipment (any external dimension < 50 cm)

EU RoHS exemption clause

6(c)

In scope of WEEE

Yes

Medium temperature range [°C] [max]

125 °C

Medium temperature range [°C] [min]

-20 °C

Output signal [mA] [max]

20 mA

Output signal [mA] [min]

4 mA

Pressure range [mbar] [max]

250 mbar

Pressure range [mbar] [min]

0 mbar

Pressure range [psi] [max]

3.63 psi

Pressure range [psi] [min]

0 psi

REACH Candidate Strip substances

Lead (CAS no. 7439-92-1)

Storage temperature range [°C] [max]

125 °C

Storage temperature range [°C] [min]

-40 °C

Storage temperature range [°F] [max]

257 °F

Storage temperature range [°F] [min]

-40 °F

Supply voltage [V] DC [max]

32 V

Supply voltage [V] DC [min]

9 V

HS Code

9026.20

• EAN 5702428878821
