Product Description
Danfoss BFP 52E Oil Pump L5. Oil pumps and accessories (Plumbing / Heat / Valves for heating and cooling systems). Principal data: shaft rotation Left, shaft diameter 8 mm. Supplied under manufacturer part number 071N3202, EAN 5702425156403, HS code 8413.60, country of origin Denmark.
Technical Specifications
- Product type
- Oil pumps and accessories
- Product group
- Heat
- Shaft rotation
- Left
- Shaft diameter
- 8 mm
- Media temperature min
- 0 °C
- Media temperature max
- 70 °C
- Power consumption
- 75 W
- Ambient temperature
- -20 to +70 °C
- REACH SVHC substance above 0.1%
- Lead
- Carbon footprint (EPD)
- 5.5990 kg CO2e per pcs
- Country of origin
- Denmark
- Customs tariff code (EU CN)
- 84136039
- HS code
- 8413.60
- Manufacturer part number
- 071N3202
- VVS number
- 369067118
- EAN
- 5702425156403
- Net weight
- 1.254 Kilogram
- Type
- BFP 52
- Rotation
- L
- 1 or 2 stage
- 2
- Actuator type
- NC+NO
- Ambient temperature [°C] [max]
- 70 °C
- Ambient temperature [°C] [min]
- -20 °C
- Approval
- CE
- Biofuel blend
- 10
- Capacity [l/h]
- 42 L/h
- Capacity group
- 25-49
- Capacity range [l/h] [Max]
- 49 L/h
- Capacity range [l/h] [Min]
- 25 L/h
- CE mark
- Yes
- China RoHS compliance
- Yes
- Closing function
- Cut-off
- Coil consumption [W]
- 9 W
- Coil Current
- AC
- Coil voltage [V]
- 220 - 230
- Comments
- Rotation and nozzle/pressure outlet are always determined viewing from the shaft end of the pump.
- Definition point [l/h]
- 2800 min-1, 10 bar, 4.3 cSt
- Description
- BFP 52E L5L, SERVICE
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(a)-I
- Factory pressure setting [bar]
- 10 bar
- Factory pressure setting stage 2 [Bar]
- 13 bar
- Filter area [cm²]
- 11 cm²
- Filter grade [µm]
- 200
- Filter type
- Cartridge
- Flats/key on the shaft
- 1 flat
- Grade of enclosure
- IP40
- Media temperature [°C] [Max]
- 70 °C
- Media temperature [°C] [Min]
- 0 °C
- NO type
- Use with NO coil
- Nozzle/pressure outlet
- L
- Number of stages
- 2
- Oil pump speed [op/min]
- 3450 op/min
- Oil type
- Kerosene/Light oil
- Pipe connection
- 2 pipes
- Power consumption [W]
- 75 W
- Pressure [bar] [Max]
- 25 bar
- Pressure [bar] [Min]
- 7 bar
- Pressure feed line [bar] [Max]
- 2 bar
- Pressure kerosene [bar] [Max]
- 12 bar
- Pressure stage 2 [bar] [Max]
- 25 bar
- REACH Candidate Strip substances
- Lead (CAS no. 7439-92-1)
- Serie
- BFP
- Shaft diameter [mm]
- 8 mm
- Speed [rpm] [Max]
- 3450 rpm
- Speed [rpm] [Min]
- 1400 rpm
- Starting torque [Nm] [Max]
- 0.12 N-m
- Storage temperature [°C] [Max]
- 70 °C
- Storage temperature [°C] [Min]
- -20 °C
- Suction Line Vacuum [bar] [Max]
- 0.4 bar
- Supply peak voltage [V] [Max]
- 253 V
- Supply peak voltage [V] [Min]
- 207 V
- Supply voltage [V]
- 230 V
- Supply voltage [V] [Max]
- 230 V
- Supply voltage [V] [Min]
- 220 V
- UL mark
- No
- Viscosity [cSt] [Max]
- 12 cSt
- Viscosity [cSt] [Min]
- 1.3 cSt
Standards & Compliance
- HS Code
- 8413.60
Cross References
- MPN 071N3202
- EAN 5702425156403
- VVS 369067118
