Danfoss AV210D 40B Solenoid Valve PTFE - 1 1/2", NO (Normally open)
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss AV210D 40B Solenoid Valve PTFE. EV220B solenoid valve (Plumbing / Heat / Valves for heating and cooling systems). Principal data: connection 1 1/2", valve position NO (Normally open). Supplied under manufacturer part number 042N4485, EAN 5702423194643, HS code 8481.80, country of origin Italy.
Technical Specifications
- Product type
- EV220B solenoid valve
- Product group
- Heat
- Connection
- 1 1/2"
- Valve position
- NO (Normally open)
- Differential pressure
- 0 - 16 bar
- Control
- Piston (angled)
- Connection internal/external
- Internal
- Media temperature
- -30 - 180 °C
- Kv value
- 46
- Housing material
- Stainless steel
- Head diameter
- 90 mm
- Closure
- Against flow
- Ambient temperature max
- 60 °C
- Orifice size
- 40 mm
- Operating pressure max
- 25 bar
- Test pressure
- 37.5 bar
- REACH SVHC substance above 0.1%
- Lead
- Carbon footprint (EPD)
- 27.8749 kg CO2e per pcs
- Country of origin
- Italy
- Customs tariff code (EU CN)
- 84818079
- HS code
- 8481.80
- Manufacturer part number
- 042N4485
- VVS number
- 470161811
- EAN
- 5702423194643
Standards & Compliance
- HS Code
- 8481.80
Cross References
- MPN 042N4485
- EAN 5702423194643
- VVS 470161811
Product Documentation
