Danfoss AMV 655 Electric Linear Valve Actuator 24 V AC — 50 mm stroke, 2000 N, 3-Point

Danfoss AMV 655 electric linear actuator, OEM order code 082G3440. Supply voltage 24 V AC (50/60 Hz). Rated stroke 50 mm, closing force 2000 N, actuator speed 2 / 6 s/mm (selectable). Control is 3-point (floating), driving Danfoss seat/globe control-valve bodies in response to a two-wire raise/lower signal. Power consumption 14 W. Enclosure IP54, protection class II per EN 60730-1. Ambient range 0 °C to 55 °C, valve media up to 200 °C, with manual override. The AMV 655 motorises large Danfoss globe/seat valve bodies (VFG 2, VFGS 2, VFU 2, VFQ 2, VF and matched series); the 50 mm stroke and 2000 N force suit the large DN range of those valves. Application: HD District Heating. Net weight 5.4 Kilogram. Data quoted verbatim from store.danfoss.com (code 082G3440).

Brand

Danfoss

Part number

082G3440

Type

AMV 655

Product group

Electrical actuators

Actuator type

Electric linear (globe-valve actuator)

Supply voltage

24 V AC

Frequency

50/60 Hz

Stroke

50 mm

Closing force

2000 N

Actuator speed

2 / 6 s/mm (selectable)

Control signal type

3-point

Position feedback

no

Safety function

No

Spring down (return)

No

Spring up

No

Power consumption

14 W

Enclosure rating

IP54

Protection class (EN 60730-1)

II

Manual override

Yes

Media temperature (max)

200 °C

Ambient temperature

0 °C to 55 °C

Application

HD District Heating

Net weight

5.4 Kilogram

Gross weight

6.3 Kilogram

EAN

5710104037271

HS code

8501.10 (electric motors/actuators of an output not exceeding 37.5 W)

Temperature Range

0 °C to 55 °C (ambient)

IP Rating

IP54

HS Code

8501.10
