Danfoss AB-QM DN 125 pressure-independent balancing & control valve, flanged (EN 1092-2), PN 16
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss AB-QM DN 125 (003Z1705) — pressure-independent balancing and control valve (PICV) for heating and cooling distribution. The integral differential-pressure controller holds the flow through the settable orifice constant regardless of pressure fluctuations in the network, combining automatic balancing, flow limitation and modulating control in one valve. Connection Flange (EN 1092-2). Valve body W.Nr.1.4027. PN 16, nominal flow 90 m³/h, media temperature -10 °C to 120 °C (media). Supplied with test plugs. OEM designation "AB-QM, DN 125, flange connection, PN16, pressure independent balancing and control valve". OEM P/N 003Z1705. Contains lead per the REACH candidate list. Technical data quoted verbatim from store.danfoss.com (code 003Z1705). Used in commercial refrigeration, provision-room cooling and reefer plant rooms across HFC, HFO and CO2 (R744) refrigerants.
Technical Specifications
- Code number
- 003Z1705
- Type
- AB-QM
- Version
- AB-QM
- Product group
- Pressure independent balancing and control valves
- Description
- AB-QM, DN 125, flange connection, PN16, pressure independent balancing and control valve
- Valve size
- DN 125
- Valve body material
- W.Nr.1.4027
- Actuator connection
- Danfoss standard
- Test plugs
- Yes
- Flow limitation
- Yes
- Flow nominal [m³/h]
- 90 m³/h
- Setting scale
- Yes
- Setting range [%] [min]
- 40 %
- Setting range [%] [max]
- 110 %
- Stroke [mm]
- 30 mm
- Leakage rate with recommended actuator (IEC 60534-4)
- Class IV
- Pressure class
- PN 16
- Differential pressure [kPa] [Min]
- 40 KPa
- Differential pressure [kPa] [Max]
- 600 KPa
- Media temperature [°C] [Min]
- -10 °C
- Media temperature [°C] [Max]
- 120 °C
- Storage and Transport temperature [°C] [Min]
- -40 °C
- Storage and Transport temperature [°C] [Max]
- 70 °C
- Contains batteries
- No
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(c)
- China RoHS compliance
- Out of scope
- REACH Candidate List substances
- Lead (CAS no. 7439-92-1)
- SCIP dossier no.
- b01c3cca-8324-4bda-8070-982597d4a155
- SCIP dossier product name
- AB-QM DN65-150
- Net weight
- 110.8 Kilogram
- Gross weight
- 119 Kilogram
- Volume
- 643.2 Liter
- EAN
- 5710104524122
Standards & Compliance
- Material
- W.Nr.1.4027
- Pressure Rating
- PN 16
- Temperature Range
- -10 °C to 120 °C (media)
- Classification / Approval
- CE
- HS Code
- 8481.80
Compatibility & Fitment
Genuine Danfoss AB-QM DN 125 PICV (003Z1705) — size to the branch/riser design flow (nominal 90 m³/h) and connection (Flange (EN 1092-2)). Fit a compatible Danfoss actuator; actuator ordered separately. Pressure class PN 16.
