Danfoss AK-XM 102A I/O extension module, 8 digital inputs

Danfoss AK-XM 102A input/output extension module for Danfoss ADAP-KOOL AK2 refrigeration system controllers (AK-SM system managers, AK-PC pack controllers, AK-CC case/evaporator controllers). Adds eight digital (on/off) inputs to a controller over the AK2 local bus for door, alarm and status signals. DIN-rail module. EAN 5702428078832.

Type

AK-XM 102A I/O extension module

Function

Additional inputs

Analog inputs (AI)

0

Digital inputs (DI)

8

Digital outputs (DO)

0

Communication bus

AK2 local bus

Net weight

0.2 kg

Gross weight

0.354 kg

Approvals

C-TICK, CE, LLC CDC TYSK, UR

Danfoss code

080Z0008

EAN

5702428078832

Code number

080Z0008

Product group

I/O and communication modules

CE mark

Yes

REACH candidate-list substances

2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol (CAS no. 79-94-7); 6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol (CAS no. 119-47-1); Diboron trioxide (B2O3, CAS no. 1303-86-2); Lead (CAS no. 7439-92-1); Lead titanium zirconium oxide (CAS no. 12626-81-2); Potassium nonafluoro-1-butanesulfonate (CAS no. 29420-49-3); Triphenyl phosphate (CAS no. 115-86-6)

Application area

Additional In- and Outputs

Communication type

AK2 LOCAL BUS

Controller type

Extension Module

Display on front

No

Division

25

EEE category

5 small equipment (any external dimension < 50 cm)

Equipment

Standard blocks

Further information

Low voltage

In scope of WEEE

Yes

PFAS content [Yes/No]

No

Power consumption

1.0 VA

EU RoHS compliance

Out of scope

Classification / Approval

C-TICK, CE, LLC CDC TYSK, UR

HS Code

9032.90
