Danfoss AK-XM 208C I/O extension module, 8 analog inputs + 4 stepper valve outputs
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss AK-XM 208C combined extension module for Danfoss ADAP-KOOL AK2 refrigeration system controllers (AK-SM system managers, AK-PC pack controllers, AK-CC case/evaporator controllers). Adds eight analog inputs and drives up to four stepper-motor expansion valves (ETS / KVS type). Supply 24 V, power consumption 13 VA. DIN-rail module. EAN 5702428446402.
Technical Specifications
- Type
- AK-XM 208C I/O extension module
- Function
- Analog inputs + stepper-motor valve outputs
- Analog inputs (AI)
- 8
- Valve outputs
- 4 (ETS / KVS stepper motor valves)
- Supply voltage
- 24 V
- Power consumption
- 13 VA
- Communication bus
- AK2 local bus
- Net weight
- 0.49 kg
- Gross weight
- 0.599 kg
- Approvals
- C-TICK, CE, LLC CDC TYSK, c UL us
- Danfoss code
- 080Z0023
- EAN
- 5702428446402
- Product group
- I/O and communication modules
- Analog inputs (AI) [pc]
- 8 pc
- Application area
- Stepper motor valve
- Approval
- C-TICK
- CE mark
- Yes
- China RoHS compliance
- Out of scope
- Controller type
- Extension Module
- Display on front
- No
- Division
- 25
- EEE category
- 5 small equipment (any external dimension < 50 cm)
- EU RoHS compliance
- Out of scope
- In scope of WEEE
- Yes
- PFAS content [Yes/No]
- No
- Power consumption [VA]
- 13 VA
- REACH Candidate List substances
- 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol (CAS no. 79-94-7)
- Supply voltage [V] DC
- 24 V
- UL mark
- Yes
Standards & Compliance
- Classification / Approval
- C-TICK, CE, LLC CDC TYSK, c UL us
- HS Code
- 9032.90
Compatibility & Fitment
Combined analog-input and stepper-valve module for the Danfoss ADAP-KOOL AK2 platform. Distinct from the AK-XM 208B (080Z0022) by its 8 added analog inputs. Confirm valve type and 24 V supply before ordering.
