Danfoss MMITSS touch screen operator panel
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss MMITSS touch-screen operator panel for the MCX programmable-controller platform. Panel-mount LCD touch display with real-time clock, over RS485 / Ethernet / Modbus. 24 V AC supply, IP54 front. EAN 5702428477628.
Technical Specifications
- Type
- MMITSS touch screen
- Function
- Touch-screen operator panel
- Supply voltage
- 24 V AC
- Frequency
- 50/60 Hz
- Communication
- RS485; Ethernet; Modbus
- Display
- LCD touch
- Real-time clock
- Yes
- Enclosure rating
- IP54
- Mounting
- Panel mount
- Power consumption
- 3.7 W
- Net weight
- 1.263 kg
- Approvals
- CE
- Danfoss code
- 080G0301
- EAN
- 5702428477628
- Product group
- Programmable controllers
- Approval
- CE
- CE mark
- Yes
- China RoHS compliance
- Out of scope
- Communication type
- ETHER
- Connector kit included
- No
- Display type
- LCD
- EEE category
- 5 small equipment (any external dimension < 50 cm)
- Enclosure rating IP
- IP54
- EU RoHS compliance
- Out of scope
- Frequency [Hz]
- 50/60 Hz
- In scope of WEEE
- Yes
- Mounting method
- Panel mounting
- Power consumption [W]
- 3.7 W
- REACH Candidate List substances
- No
- Supply voltage [V] AC
- 24 V
Standards & Compliance
- IP Rating
- IP54
- Classification / Approval
- CE
- HS Code
- 9032.90
Compatibility & Fitment
Touch-screen operator panel for Danfoss MCX controllers over RS485 / Ethernet / Modbus. The smaller-screen sibling is the MMITXS (080G0302). Confirm controller communication (RS485/Modbus) and panel cut-out before ordering.
