Danfoss MBS 4251 Pressure Transmitter 0–16 bar 4–20 mA
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss MBS 4251 compact pressure transmitter, genuine OEM code 060G6114. Two-wire 4–20 mA output over a measuring range of 0–16 bar (0–232 psi), supply voltage 10–28 V DC. Pressure connection 1/4-18 NPT male; electrical connection Angular connector Pg 9 (EN 175301-803-A). Accuracy ≤ ±0.5 % FS (typical). Wetted parts AISI 316L stainless steel; enclosure IP65. Approvals: ATEX intrinsically safe Ex ia IIC T5.T4 Ga/Gb, CE, UL Recognized (C UL US). EAN 5702428484985.
Technical Specifications
- Brand
- Danfoss
- Part number
- 060G6114
- Type
- MBS 4251 pressure transmitter
- Category
- Sensors & Instrumentation — Pressure Transmitters
- Measuring range
- 0–16 bar (0–232 psi)
- Reference
- gauge (relative)
- Output signal
- 4–20 mA (2-wire)
- Supply voltage
- 10–28 V DC
- Accuracy
- ≤ ±0.5 % FS typical, ≤ ±1.0 % FS maximum
- Pressure connection
- 1/4-18 NPT male
- Electrical connection
- Angular connector Pg 9 (EN 175301-803-A)
- Wetted parts
- AISI 316L stainless steel
- Compensated temperature range
- 0 to +100 °C
- Medium temperature
- -20 to +125 °C
- Enclosure rating
- IP65
- EAN
- 5702428484985
- Approvals
- ATEX intrinsically safe Ex ia IIC T5..T4 Ga/Gb, CE, UL Recognized (C UL US)
- HS code
- 9026.20
- Net weight
- 0.186 Kilogram
- Product group
- Sensors
- + supply
- Pin 1
- - common
- Pin 2
- Accuracy, max. [±FS%]
- 1 %
- Accuracy, typical [±FS%]
- 0.5 %
- Adj. zero point and span
- No
- Approval
- ATEX
- CE mark
- Yes
- China RoHS compliance
- Out of scope
- Compensated temp. range [°C] [max]
- 100 °C
- Compensated temp. range [°C] [min]
- 0 °C
- Compensated temp. range [°F] [max]
- 212 °F
- Compensated temp. range [°F] [min]
- 32 °F
- EEE category
- 5 small equipment (any external dimension < 50 cm)
- Electrical conn. Male/Female
- Male and Female
- Electrical connection size
- Pg 9
- Electrical connection standard
- EN 175301-803-A
- Enclosure rating IP
- IP65
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(c)
- EX Sales text
- Ex iA IIC T5..T4 Ga/Gb
- Flush diaphragm
- No
- High Clipping Level
- 22.4
- In scope of WEEE
- Yes
- International Article Number
- 5702428484985
- Intrinsically safe
- Yes
- Low Clipping level
- 3.6
- Medium temperature range [°C] [max]
- 125 °C
- Medium temperature range [°C] [min]
- -20 °C
- Medium temperature range [°F] [max]
- 257 °F
- Medium temperature range [°F] [min]
- -4 °F
- Non-linearity BFSL [±FS%]
- 0.2 %
- Output signal [mA] [max]
- 20 mA
- Output signal [mA] [min]
- 4 mA
- Overload pressure max. [bar]
- 96 bar
- Overload pressure max. [psi]
- 1392 psi
- Pressure connection HEX [mm]
- 27 mm
- Pressure connection size
- 1/4-18
- Pressure connection standard
- ANSI/ASME B1.20.1
- Pressure connection type
- NPT
- Pressure Male/Female
- Male
- Pressure range [bar] [max]
- 16 bar
- Pressure range [bar] [min]
- 0 bar
- Pressure range [psi] [max]
- 232 psi
- Pressure range [psi] [min]
- 0 psi
- Pressure reference
- Sealed gauge
- Pulse-snubber
- Yes
- REACH Candidate List substances
- Lead (CAS no. 7439-92-1)
- Response time max. [ms]
- 4 ms
- Specification key
- MBS 4251-2231-A1AC04-0
- Supply voltage [V] DC [max]
- 28 V
- Supply voltage [V] DC [min]
- 10 V
- UL mark
- Yes
Standards & Compliance
- Size / Series
- 1/4-18 NPT male
- Material
- AISI 316L stainless steel wetted parts
- Thread Standard
- 1/4-18 NPT male
- Pressure Rating
- 0–16 bar (0–232 psi)
- Temperature Range
- Compensated 0 to +100 °C; medium -20 to +125 °C
- IP Rating
- IP65
- HS Code
- 9026.20
Compatibility & Fitment
Select the measuring range and pressure/electrical connection to suit the application. 2-wire 4–20 mA loop; observe supply voltage 10–28 V DC and load limits.
