Danfoss EVRA 25 Solenoid Valve Flange Refrigeration 032F6226
Danfoss · HVAC & Refrigeration · Solenoid Valves
Danfoss EVRA 25 servo-operated piston solenoid valve body, OEM P/N 032F6226. Controls the flow of liquid, suction and hot-gas refrigerant — including ammonia (R717) and fluorinated refrigerants — in industrial refrigeration plant. Two-way valve with flange inlet and outlet connections, cast iron (GJS-400-18-LT) body. Orifice 25 mm, Kv 10 m³/h. Minimum opening pressure differential 0.2 bar. Max working pressure 42 bar (609 psig); media temperature -40 °C to 105 °C. Manual stem operation: No. The coil is ordered separately (AC or DC). Flange gaskets and bolts are included; flanges are ordered separately. Refrigerant and charge limits are listed on the datasheet — verify against your system.
Specifications
- Part number
- 032F6226
- HS code
- 8481.80
- Material
- Cast iron (GJS-400-18-LT) body — full material breakdown in the EVRA datasheet
- Pressure rating
- 42 bar (609 psig) max working pressure
- Temperature range
- -40 °C to 105 °C
Compatibility
Pilot/servo-operated solenoid valve for liquid, suction and hot-gas lines (ammonia and fluorinated refrigerants) in industrial refrigeration. Coil ordered separately. Flange connections — verify code and connection size before ordering. Image is a generic solenoid-valve category placeholder (no fabricated brand artwork).
Standards
Approvals
