Product Description
Carlo Gavazzi DMB71CM24 is a multifunction time relay with two change-over outputs at 5 A and a selectable time range from 0.1 s to 360,000 s. Universal control voltage 24-240 V AC/DC with screw connections; the 35.5 mm module snaps onto 35 mm DIN rail. Supported functions include on-delay, off-delay, pulse shaping and flashing.
Technical Specifications
- Manufacturer part number (MPN)
- DMB71CM24
- EAN / GTIN
- 8030956017434
- HS code
- 8536.90
- Sales unit
- pcs
- Degree of protection (IP)
- IP20
- Suitable for front mounting
- No
- Complete with socket
- Yes
- Material of contact insert
- Thermoplastic
- Voltage type (operating voltage)
- AC/DC
- Type of electric connection
- Screw connection
- Function delay-on energization
- Yes
- Function delay on de-energization
- Yes
- Function floating contact on energization
- Yes
- Function floating contact on de-energization
- Yes
- Function star-delta
- No
- Function pulse shaping
- Yes
- Function flashing, starting with pause, fixed time
- Yes
- Function flashing, starting with pulse, fixed time
- Yes
- Clock function, starting with pause, variable
- No
- Clock function, starting with pulse, variable
- No
- With plug-in socket
- No
- Remote operation possible
- No
- Suitable as remote control
- No
- Pluggable on auxiliary contact block
- No
- Rated control supply voltage AC 50 Hz
- 24–240 V
- Rated control supply voltage AC 60 Hz
- 24–240 V
- Rated control supply voltage DC
- 24 V
- Voltage type for actuating
- AC/DC
- Nominal current
- 5 A
- Time range
- 0.1–360000 s
- Number of outputs, delayed, change-over contact
- 2
- Outputs, reversible delayed/undelayed
- No
- With semiconductor output
- No
- Suitable for DIN rail (top hat rail) mounting
- Yes
- Width
- 35.5 mm
- Height
- 81 mm
- Depth
- 67.2 mm
- Country of origin
- Italy
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 8030956017434
- SAP 1000140791
- Code 81132415
Product Documentation
