3-Phase nettvakt over-/underspg. 208-240V (PPB01CM23)

Carlo Gavazzi PPB01CM23 Manufacturer description: 3-phase monitoring relay for phase loss, sequence, over or undervoltage, nominal range 208-240 V AC, delay on alarm 0.1-30 s, SPDT relay output, regenerated voltage detection, 36 mm plug-in housing. PPB01CM23 Phase monitoring relay.

Manufacturer part number (MPN)

PPB01CM23

EAN / GTIN

8030956001006

Sales unit

pcs

Mounting

Plug-in

Function

Phase loss; Phase sequence; Overvoltage; Undervoltage

3-phase voltage range

208-240 Vac

Frequency range

50-60 Hz; 50-400 Hz

Output

1 relay

Time delay

No delay adjustment

Approvals, marks, declarations

for Europe; for North America; for Australia

Setting method through NFC

No

E-number (NO)

4367523

Type of electric connection

Plug-in connection

Rated control supply voltage AC 50 Hz

208–240 V

Rated control supply voltage AC 60 Hz

208–240 V

Voltage type for actuating

AC

Voltage measuring range

208–240 V

Min. adjustable delay-on energization time

0 s

Min. adjustable off-delay time

0.1 s

Max. permitted off-delay time

30 s

Number of contacts as change-over contact

1

Width

36 mm

Height

80 mm

Depth

94 mm

Country of origin

Italy

HS Code

9030.90

• EAN 8030956001006
• SAP 1000140284
• Code 81132090
