Wibe Group W4-75 Vertical Riser Bend, Steel Zinc+
Pricing
Request a quote
We reply within 24 hours
Product Description
Wibe Group CSU796015 is a vertical riser bend for the W4-75 cable tray system in steel with Zinc+ surface protection, rated corrosion class C4. The segmental bend is adjustable and measures 250 x 77 x 16 mm with 1 mm material thickness, supplied without connector. Typical applications include vertical direction changes in cable tray runs within industrial and commercial installations.
Technical Specifications
- Manufacturer part number (MPN)
- CSU796015
- EAN / GTIN
- 7321677960156
- Sales unit
- pcs
- Length
- 250 mm
- Width
- 77 mm
- Height
- 16 mm
- Material
- Steel
- Material type or surface treatment
- Zinc+
- Corrosion class
- C4
- Change of direction
- Rising/descending
- Angle
- Adjustable
- Construction type
- Vertical adjustable bend element
- Bend model
- Segmental bend
- With cover
- No
- Cable tray height
- 15 mm
- Cable tray width
- 75 mm
- Material thickness
- 1 mm
- Side wall perforation
- No
- Mounting perforation in bottom
- Yes
- NATO
- Yes
- Model
- Without connector
- Suitable for circuit integrity
- No
- Stainless steel, pickled
- No
- Surface protection
- Hot-dip galvanized
- Pack 1 type
- Each
- Quantity pack 1
- 1
- Weight pack 1
- 0.22 kg
- Length pack 1
- 250 mm
- Width pack 1
- 77 mm
- Height pack 1
- 16 mm
- Net weight
- 0.22 kg
- Country of origin
- SE
- ETIM class
- EC002400
- GWP Total A1-A3
- 0.6248 kgCO2e
Standards & Compliance
- HS Code
- 7308.90
Cross References
- EAN 7321677960156
- SAP 1200851978
- Code 84073139
Product Documentation
