Splicing connector with levers, for all conductor types, max. 4 mm², 10-Conductor
Pricing
Request a quote
We reply within 24 hours
Product Description
WAGO 221-490 Manufacturer description: Splicing connector with levers; for all conductor types; for Ex e applications; max. 4 mm²; 10-conductor; transparent housing; Operating temperature (max.): 105 °C; 4,00 mm²; transparent. Terminal block 4mm2 10-Conductor. Connection Terminals for all types of conductors. for Ex e-applications.
Technical Specifications
- Manufacturer part number (MPN)
- 221-490
- EAN / GTIN
- 4066966668087
- Sales unit
- pcs
- Package quantity
- 15 pcs
- Clamping units
- 10
- Total number of potentials
- 1
- Width
- 29.8 mm / 1.173 inches
- Height
- 15.8 mm / 0.62 inches
- Depth
- 18.3 mm / 0.72 inches
- Color
- transparent
- Cover color
- transparent
- Material group
- IIIa
- Insulation material (main housing)
- Polycarbonate (PC)
- Flammability class per UL94
- V2
- Fire load
- 0.112 MJ
- Actuator color
- light gray
- Weight
- 7 g
- Ambient temperature (operation)
- +85 °C
- Temperature marking per EN 60998
- T85
- PU (SPU)
- 150 (15) pcs
- Packaging type
- Box
- Country of origin
- DE
- Customs tariff number
- 85369010000
- UNSPSC
- 39,121,409
- ETIM 9.0
- EC000446
- ETIM 10.0
- EC000446
- ECCN
- NO US CLASSIFICATION
- RoHS Compliance Status
- Compliant,No Exemption
- Conductor cross-section
- 4 mm²
- Nominal current
- 32 A
- Nominal voltage
- 450 V
- Colour
- Grey
- Number of clamp positions
- 10
- Suitable for solid conductors
- Yes
- Conductor cross section solid (solid, stranded)
- 0.2–4 mm²
- AWG-range
- 12–24
- Nominal cross section
- 0.2–4 mm²
- Suitable for multi-wire conductors
- Yes
- Suitable for flexible conductors
- Yes
- Transparent
- Yes
- With operation lever
- Yes
- Min. AWG-size
- 24
- Max. AWG-size
- 12
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4066966668087
- SAP 1200832003
- Code 84016459
