WAGO 285-195 Two-Conductor DIN-Rail Terminal Block, 95 mm², Grey
Pricing
Request a quote
We reply within 24 hours
Product Description
WAGO 285-195 is a high-current DIN-rail terminal block with two spring-clamp positions rated for conductors up to 95 mm², at 232 A and 1000 V. It mounts on 35 mm top-hat rail and measures 25 mm wide by 107 mm high by 101 mm deep. Housing is thermoplastic, rated for 105 degrees C operating temperature, in grey. Supplied in packs of 5 pieces.
Technical Specifications
- Manufacturer part number (MPN)
- WAGO 285-195
- EAN / GTIN
- 4017332601214
- Sales unit
- pcs
- Package quantity
- 5 pcs
- Conductor cross-section
- 95 mm²
- Connectable conductor cross section solid-core
- 25–95 mm²
- Connectable conductor cross section multi-wired
- 25–95 mm²
- Rated current In
- 232 A
- Rated voltage
- 1000 V
- Type of electrical connection 1
- Spring clamp connection
- Type of electrical connection 2
- Spring clamp connection
- Number of levels
- 1
- Number of clamp positions per level
- 2
- Mounting method
- DIN rail (top hat rail) 35 mm
- Material insulation body
- Thermoplastic
- Operating temperature
- 105 °C
- Width
- 25 mm
- Height
- 107 mm
- Depth
- 101 mm
- Explosion-tested version 'Ex e'
- No
- Closing plate required
- No
- Colour
- Grey
- Internally connected stages
- No
- Country of origin
- Poland
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4017332601214
- SAP 1000028012
- Code 8207937
