Jumper; 6-Way; insulated; light gray (2001-406)
Pricing
Request a quote
We reply within 24 hours
Product Description
WAGO 2001-406 Manufacturer description: Jumper; 6-way; insulated; light gray. Insulated jumper link, 6-pole, 1,5mm², 18A. Light grey.
Technical Specifications
- Manufacturer part number (MPN)
- 2001-406
- EAN / GTIN
- 4017332998819
- Sales unit
- pcs
- Package quantity
- 25 pcs
- Number of spacings
- 6 -fach
- Rated current
- 18 A
- Width
- 23.9 mm / 0.941 inches
- Height
- 4.1 mm / 0.161 inches
- Depth
- 19 mm / 0.748 inches
- Color
- light gray
- Insulation material (main housing)
- Polyamide (PA66)
- Flammability class per UL94
- V0
- Fire load
- 0.016 MJ
- Weight
- 2.2 g
- Product Group
- 22 (TOPJOB S)
- PU (SPU)
- 25 pcs
- Packaging type
- Bag
- Country of origin
- DE
- Customs tariff number
- 85366990990
- UNSPSC
- 39,121,421
- eCl@ss 10.0
- 27-14-11-40
- eCl@ss 9.0
- 27-14-11-40
- ETIM 9.0
- EC000489
- ETIM 10.0
- EC000489
- ECCN
- NO US CLASSIFICATION
- RoHS Compliance Status
- Compliant,No Exemption
- EAN
- 4055143699112
- MPN
- 2001-406
- Mounting method
- Pluggable
- Colour
- Grey
- Model
- Transverse connector
- Insulated
- Yes
- Rated voltage
- 800 V
- Modular spacing
- 4.2 mm
- Number of bridged clamps
- 6
- With contact protection
- Yes
- Rated current In
- 18 A
- Explosion-tested version 'Ex e'
- Yes
Standards & Compliance
- HS Code
- 8536.69
Cross References
- EAN 4017332998819
- SAP 1000039708
- Code 8752719
Product Documentation
More from WAGO
WAGO
Switched-mode power supply; Eco; 1-Phase; 24 VDC output voltage; 5 A output current; DC-OK LED
787-1722
WAGO
Jumper; insulated; gray
285-450
WAGO
WMB marking card, 71 ... 80 (10X), stretchable 5 - 5.2 mm
793-5571
WAGO
Innpluglemme 8X4MM² in blister
2773-408/995-005
WAGO
Strain relief housing; 4-Pole; for 2 cables; 9.0 … 13.0 mm; 55 mm; black
770-504
WAGO
Flat cable end cover; 5-Pole; for flat cable 5 x 2.5/4 mm²; Plastic; transparent
897-250
WAGO
WAGO Pro 2 Single-Phase Power Supply 24 VDC 20 A
2787-2147
WAGO
Jumper; 10-Way; insulated; light gray (2004-410)
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 2001-406?
- 2001-406 can be ordered from cballast.com as a WAGO catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this WAGO product?
- The manufacturer part number is 2001-406.
- What is the HS code for 2001-406?
- The customs tariff (HS) code for 2001-406 is 8536.69.
- Who manufactures 2001-406?
- 2001-406 is a WAGO product in the Electrical Components range.
- Is a datasheet available for 2001-406?
- Yes — the 2001-406 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 2001-406?
- The minimum order quantity is 1.
- Is 2001-406 available?
- Yes — 2001-406 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
