Telemecanique XUYPSCO989SP Photoelectric Sensor, Background Suppression, Red Light, Sn 80 mm, PNP, M8 connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XUYPSCO989SP XUY photoelectric sensor, background suppression, red-light emitter, Sn 80 mm, PNP output, M8 connector.
Technical Specifications
- Manufacturer part number (MPN)
- XUYPSCO989SP
- EAN / GTIN
- 3666916031995
- Sales unit
- pcs
- Package quantity
- 35 pcs
- Output type
- PNP
- Adjustment range
- 0–4000 mm
- Triangulation
- Background fade-out
- Pre failure notice
- No
- With time function
- No
- Rated switching distance
- 4000 mm
- Max. switching distance
- 4000 mm
- Max. output current
- 25 mA
- With reflector
- No
- Analogue output 0 V ... 10 V
- No
- Analogue output 0 mA ... 20 mA
- No
- Analogue output 4 mA ... 20 mA
- No
- Analogue output -10 V ... +10 V
- No
- With other analogue output
- No
- With communication interface analogue
- No
- With communication interface AS-Interface
- No
- With communication interface CANOpen
- No
- With communication interface DeviceNet
- No
- With communication interface Ethernet
- No
- With communication interface INTERBUS
- No
- With communication interface PROFIBUS
- No
- With communication interface RS-232
- No
- With communication interface RS-422
- No
- With communication interface RS-485
- No
- With communication interface SSD
- No
- With communication interface SSI
- No
- Type of electric connection
- Connector M8
- Type of switching output
- PNP/PNP
- Type of switch function
- Programmable/configurable
- Operation agent-safety class
- Safety class 0
- Construction type housing
- Special construction
- Width sensor
- 20 mm
- Height of sensor
- 32 mm
- Length of sensor
- 13 mm
- Sensing mode
- Light switching
- Material of optical surface
- Plastic
- Housing material
- Plastic
- Max. output current at protected output
- 25 mA
- Min. reflector distance
- 0 mm
- Ambient temperature
- 0–50 °C
- Response time
- 1 ms
- Switching frequency
- 500 Hz
- Type of safety according to IEC 61496-1
- 1
- Rated control supply voltage DC
- 12–24 V
- Voltage type
- AC/DC
- With monitoring function downstream switching devices
- No
- Type of light
- Laser diode, red light
- With restart blockage
- No
- Suitable for safety functions
- No
- Degree of protection (IP)
- IP67K
- Operating distance
- 0–4000 mm
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916031995
- SAP 1000341338
- Code 8375829
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique OsiSense XS130BHPBL2 Inductive Proximity Sensor — M30 barrel, Sn 15 mm, PNP, NC, pre-wired cable (2 m)
Telemecanique
Telemecanique ZC2JY91 Limit Switch Operating Lever, Spring Rod (Cat's Whisker)
Telemecanique
Telemecanique XUX2APANT16R Photoelectric Through-Beam Receiver, Plastic, PNP, NO, Screw terminals
Telemecanique
Telemecanique XY2CE1A297 Emergency Stop Rope Pull Switch, with Reset
Telemecanique
Telemecanique XUSL4E4BB091LWC Safety Light Grid Type 4, Body Detection, 4 Beams, 910 mm
Telemecanique
Telemecanique OsiSense XS212B4PAL5 Inductive Proximity Sensor — Ø5 mm barrel, Sn 8 mm, PNP, NO, pre-wired cable
Telemecanique
4316570 (ZC2JD28)
Telemecanique
Telemecanique XUY420NA4H03M12 Photoelectric Sensing Bar 420 mm, IP50, M12 Connector
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XUYPSCO989SP?
- XUYPSCO989SP can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XUYPSCO989SP.
- What is the HS code for XUYPSCO989SP?
- The customs tariff (HS) code for XUYPSCO989SP is 8536.50.
- Who manufactures XUYPSCO989SP?
- XUYPSCO989SP is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for XUYPSCO989SP?
- Yes — the XUYPSCO989SP datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XUYPSCO989SP?
- The minimum order quantity is 1.
- Is XUYPSCO989SP available?
- Yes — XUYPSCO989SP is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
