Telemecanique XUYPCO925L1ANSP Laser Photoelectric Sensor, Analogue 0–10 V, Sn 60 mm
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XUYPCO925L1ANSP XUY laser photoelectric sensor, analogue 0–10 V output, Sn 60 mm.
Technical Specifications
- Manufacturer part number (MPN)
- XUYPCO925L1ANSP
- EAN / GTIN
- 3666916029039
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Nominal sensing distance Sn
- 60 mm
- Output signal
- 0–10 V
- Voltage type
- AC/DC
- Max. output current
- 35 mA
- Housing material
- Plastic
- Suitable for safety functions
- No
- Ambient temperature
- 0–45 °C
- With time function
- No
- Switching frequency
- 40 Hz
- Type of electric connection
- Connector M12
- Rated control supply voltage AC 50 Hz
- 18–28 V
- Operation agent-safety class
- Safety class 0
- Construction type housing
- Cuboid
- Laser protection class
- Class 2
- Max. output current at protected output
- 35 mA
- Min. reflector distance
- 1000 mm
- With monitoring function downstream switching devices
- No
- With restart blockage
- No
- Response time
- 0.5 ms
- Transmission range of the safety field
- 0.3 m
- Type of safety according to IEC 61496-1
- 1
- Operating distance
- 60 mm
- Pre failure notice
- No
- Material of optical surface
- Plastic
- Degree of protection (IP)
- IP67K
- Analogue output 0 V ... 10 V
- No
- Analogue output 0 mA ... 20 mA
- No
- Analogue output -10 V ... +10 V
- No
- Analogue output 4 mA ... 20 mA
- No
- Width sensor
- 17 mm
- Height of sensor
- 50 mm
- With communication interface analogue
- No
- With communication interface AS-Interface
- No
- With communication interface CANOpen
- No
- With communication interface DeviceNet
- No
- With communication interface Ethernet
- No
- With communication interface INTERBUS
- No
- With communication interface PROFIBUS
- No
- With communication interface RS-232
- No
- With communication interface RS-422
- No
- With communication interface RS-485
- No
- With communication interface SSD
- No
- With communication interface SSI
- No
- Length of sensor
- 50 mm
- Max. switching distance
- 1000 mm
- With reflector
- No
- With other analogue output
- No
- Sensing mode
- Light switching
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916029039
- SAP 1000341345
- Code 8997562
Product Documentation
