Element (ZC2JD4)
Pricing
Request a quote
We reply within 24 hours
Overview
Telemecanique Element (ZC2JD4) is listed under Sensors & Instrumentation / Position Switches. Sales unit: pcs; Package quantity: 12 pcs; Switching function: Quick-break switch; Housing material: Metal; Suitable for safety functions: No; With status indication: No.
Technical Specifications
- Manufacturer part number (MPN)
- ZC2JD4
- EAN / GTIN
- 3666916042946
- Sales unit
- pcs
- Package quantity
- 12 pcs
- Switching function
- Quick-break switch
- Rated operation current Ie at AC-15, 230 V
- 3 A
- Rated operation current Ie at DC-13, 230 V
- 0.27 A
- Housing material
- Metal
- Suitable for safety functions
- No
- With status indication
- No
- Type of interface for safety communication
- None
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Construction type housing
- Cuboid
- Degree of protection (IP)
- IP65
- Forced opening
- No
- Type of control element
- None
- Type of interface
- None
- Output electronic
- No
- Width sensor
- 42 mm
- Height of sensor
- 81 mm
- Length of sensor
- 41 mm
- Switching function latching
- No
- Ambient temperature during operating
- -25–70 °C
- Number of contacts as change-over contact
- 2
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916042946
- SAP 1000257157
- Code 8135858
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XCSRC31MM12 Safety Limit Switch, M12 connector
Telemecanique
Telemecanique XZCPB1141L2 Sensor Cable, M12 female straight, 4-pin, PUR, 2 m
Telemecanique
Telemecanique XMEP7K5PT730 Pressure Transmitter, G 1/4 A, 0.5–4.5 V ratiometric, Deutsch DT04 connector
Telemecanique
Telemecanique XMLA070E2S11 Pressure Switch, 5–70 bar
Telemecanique
Telemecanique OsiSense XS8C1A1PAL10 Inductive Proximity Sensor — 40 × 40 mm block, Sn 25 mm, PNP, NO, pre-wired cable
Telemecanique
Telemecanique XUSL4E2BB051LWC Safety Light Grid Type 4, Body Detection, 2 Beams, 510 mm
Telemecanique
Telemecanique XCSE83127 Safety Limit Switch with Guard Locking, 24 V
Telemecanique
Telemecanique XMEP1K0PT230 Pressure Transmitter, G 1/4 A, 0.5–4.5 V ratiometric, Deutsch DT04 connector
Technical guides
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy ZC2JD4?
- ZC2JD4 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is ZC2JD4.
- What is the HS code for ZC2JD4?
- The customs tariff (HS) code for ZC2JD4 is 8536.50.
- Who manufactures ZC2JD4?
- ZC2JD4 is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for ZC2JD4?
- Yes — the ZC2JD4 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for ZC2JD4?
- The minimum order quantity is 1.
- Is ZC2JD4 available?
- Yes — ZC2JD4 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
