Telemecanique XMLP016BC71F Pressure Transmitter, 0.5–4.5 V ratiometric, G 1/4, DIN connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XMLP016BC71F OsiSense XMLP pressure transmitter, 0.5–4.5 V ratiometric output, G 1/4 process connection, DIN connector.
Technical Specifications
- Manufacturer part number (MPN)
- XMLP016BC71F EAN / GTIN: 3666916023143 Sales unit: pcs Package quantity: 24 pcs Pressure: 16 bar Depth: 60.6 mm With display: No Diameter: 26 mm With manual on/off switch: No Initial setting: 0–16000 hPa End setting: 0–16000 hPa Max. operation pressure: 16000 hPa Explosion-proof: No Degree of protection (IP): IP65/IP67 Switch off pressure: 0–16 bar Rated voltage Ue at DC: 24 V Bursting pressure: 48 bar Engaging pressure: 0–16 bar Electronic version: Yes End value measuring range pressure: 1600000 Pa Suitable as 2-point controller: No Suitable as limiter: No Suitable as guard: Yes Max. test pressure: 32 bar Medium temperature: -20–120 °C With hand operation: No Max. operating pressure: 16000 hPa Country of origin: Switzerland
Standards & Compliance
- HS Code
- 9026.20
Cross References
- EAN 3666916023143
- SAP 1200045288
- Code 81877262
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XUSL4E14F061N Safety Light Curtain Type 4, Finger Detection (14 mm), 610 mm Height
Telemecanique
Telemecanique XZCPV0666L2 Sensor Cable, M8 female, 3-pin, PVC, 2 m
Telemecanique
Telemecanique XMLP040BD21FQ Pressure Transmitter, 0.5–4.5 V ratiometric, G 1/4, M12 connector
Telemecanique
Telemecanique XXR18A4KAM12 Ultrasonic Sensor (Through-Beam Receiver) M18, PNP/NPN selectable, NO, M12 connector
Telemecanique
Telemecanique XUSL4MB40H196N Type 4 Safety Light Grille with Integrated Muting, 1960 mm protected height
Telemecanique
Telemecanique XUSL4E14F061NS1 Safety Light Curtain Type 4, Finger Detection (14 mm), 610 mm Height
Telemecanique
Telemecanique XCKD limit switch, metal body, M18 threaded plunger head, 1 NC + 1 NO, snap action with positive opening, M12 connector, IP66/IP67 XCKD21H2M12
Telemecanique
Telemecanique XMLR025G2N06 Pressure Sensor with Display, 0–25 bar, 2× NPN
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XMLP016BC71F?
- XMLP016BC71F can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XMLP016BC71F.
- What is the HS code for XMLP016BC71F?
- The customs tariff (HS) code for XMLP016BC71F is 9026.20.
- Who manufactures XMLP016BC71F?
- XMLP016BC71F is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for XMLP016BC71F?
- Yes — the XMLP016BC71F datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XMLP016BC71F?
- The minimum order quantity is 1.
- Is XMLP016BC71F available?
- Yes — XMLP016BC71F is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
