Telemecanique XCKD limit switch, metal body, M18 threaded plunger head, 1 NC + 1 NO, snap action with positive opening, M12 connector, IP66/IP67 XCKD21H2M12

Telemecanique XCKD21H2M12 position (limit) switch, metal body, with an M18 threaded plunger head. 1 NC + 1 NO contact block, snap action, with positive (forced) opening on the NC contact. Connection is by M12 plug rather than a cable gland, so it wires up with a standard M12 cordset and needs no enclosure entry. Protection IP66/IP67.

Manufacturer part number (MPN)

XCKD21H2M12

EAN / GTIN

3666916094808

HS code

8536.90

Sales unit

pcs

Package quantity

21 pcs

Switching function

Quick-break switch

Rated operation current Ie at AC-15, 230 V

3 A

Rated operation current Ie at DC-13, 230 V

0.27 A

Housing material

Metal

Suitable for safety functions

No

With status indication

No

Type of interface for safety communication

None

Type of electric connection

Connector M12

Explosion safety category for gas

None

Explosion safety category for dust

None

Construction type housing

Cuboid

Degree of protection (IP)

IP66/IP67

Forced opening

Yes

Type of control element

Plunger

Type of interface

None

Output electronic

No

Width sensor

31 mm

Height of sensor

65 mm

Length of sensor

30 mm

Switching function latching

No

Ambient temperature during operating

-25–70 °C

Number of contacts as normally closed contact

1

Number of contacts as normally open contact

1

Country of origin

Indonesia

HS Code

8536.90

• EAN 3666916094808
• SAP 1000341126
• Code 8975125
