Telemecanique XCKM510H29 Limit Switch, Metal Plunger, 1 NO + 1 NC, M20 entry
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCKM510H29 limit switch (position switch), metal plunger actuator, 1 NO + 1 NC contacts, M20 entry.
Technical Specifications
- Manufacturer part number (MPN)
- XCKM510H29
- EAN / GTIN
- 3666916057018
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 32 pcs
- Contact configuration
- NO + NC
- Switching function
- Slow-action switch and quick-break switch
- Rated operation current Ie at AC-15, 230 V
- 3 A
- Rated operation current Ie at DC-13, 230 V
- 0.27 A
- Housing material
- Metal
- Suitable for safety functions
- No
- With status indication
- No
- Type of interface for safety communication
- None
- Type of electric connection
- Cable entry metrical
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Construction type housing
- Cuboid
- Degree of protection (IP)
- IP66/IP67
- Forced opening
- Yes
- Type of control element
- Plunger
- Type of interface
- None
- Output electronic
- No
- Width sensor
- 63 mm
- Height of sensor
- 64 mm
- Length of sensor
- 30 mm
- Switching function latching
- No
- Ambient temperature during operating
- -25–70 °C
- Number of contacts as normally closed contact
- 1
- Number of contacts as normally open contact
- 1
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3666916057018
- SAP 1000063834
- Code 8899573
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XS112BLPAM12 Inductive Sensor, Ø12 mm Threaded Body, PNP, M12 Connector, Shielded
Telemecanique
Telemecanique XCMD2145L1 Limit Switch, Adjustable-Length Roller Lever, Metal Body, 1 m cable
Telemecanique
Telemecanique OsiSense XS618B1MBL10 Inductive Proximity Sensor — M18 barrel, Sn 8 mm, 2-Wire AC/DC, NC, pre-wired cable
Telemecanique
Telemecanique ZCKJ5D Limit Switch Body, Metal, NO+NC, Slow-break
Telemecanique
Telemecanique XUSL4MA30H061N Type 4 Safety Light Grille with Integrated Muting, 610 mm protected height
Telemecanique
Telemecanique OsiSense XS630B1DAL2 Inductive Proximity Sensor — M30 barrel, Sn 15 mm, 2-Wire DC, NO, pre-wired cable (2 m)
Telemecanique
Telemecanique OsiSense XS630B1DBL2 Inductive Proximity Sensor — M30 barrel, Sn 15 mm, 2-Wire DC, NC, M12 connector (4-Pin)
Telemecanique
Telemecanique OsiSense XS612B1NAL5 Inductive Proximity Sensor — M12 barrel, Sn 4 mm, NPN, NO, pre-wired cable
Technical guides
- Limit Switch and Position Switch Finder — by Actuator (Roller Plunger, Roller Lever, Rod Lever, Plunger, Spring Rod) and Contacts — Telemecanique XCK, Siemens 3SE5, Eaton LS, R. Stahl Ex
- Emergency Stop Rope Pull Switches — Covering Conveyors to EN ISO 13850 with XY2C
- Inductive Proximity Sensors — Diameter, Sensing Distance, Flush Mounting, PNP/NPN and NO/NC Explained
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCKM510H29?
- XCKM510H29 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCKM510H29.
- What is the HS code for XCKM510H29?
- The customs tariff (HS) code for XCKM510H29 is 8536.90.
- Who manufactures XCKM510H29?
- XCKM510H29 is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for XCKM510H29?
- Yes — the XCKM510H29 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCKM510H29?
- The minimum order quantity is 1.
- Is XCKM510H29 available?
- Yes — XCKM510H29 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
