Telemecanique XCSDMR79010 Coded Magnetic Safety Switch, Cylindrical M30, NO+NO, 10 m cable
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique Preventa XCSDMR79010 coded magnetic safety switch, cylindrical M30 body, NO+NO contacts, 10 m cable; for position monitoring of guards and doors.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMR79010
- EAN / GTIN
- 3666916059463
- HS code
- 8544.42
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Length of sensor
- 38.5 mm
- Diameter sensor
- 30 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cylinder, screw-thread
- Housing material
- Plastic
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8544.42
Cross References
- EAN 3666916059463
- SAP 1000342336
- Code 81106752
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique OsiSense XS7G12PC440 Inductive Proximity Sensor — flat rectangular, Sn 2 mm, PNP, NO or NC, pre-wired cable (2 m)
Telemecanique
Telemecanique XUK0ARCTL10 Multimode Photoelectric Sensor, Plastic, AC/DC Multi-Voltage, Relay Output, 10 m cable
Telemecanique
Telemecanique XMLP160BC71F Pressure Transmitter, 0.5–4.5 V ratiometric, G 1/4, DIN connector
Telemecanique
Telemecanique XX9D1A1F1M12 Ultrasonic Sensor, Sn 1 m, 0–10 V, M12 connector
Telemecanique
Telemecanique XS1N30PA349SBTF Inductive Sensor M30, PNP NO, 12–24 V, Low Temperature
Telemecanique
Telemecanique XUX8AKSAT16 Photoelectric Sensor, Background Suppression, Plastic, PNP/NPN selectable, M12 connector
Telemecanique
Telemecanique XCMD2102L3 Limit Switch, Metal Roller Plunger
Telemecanique
Telemecanique XUK9ARCNL10 Photoelectric Sensor, Polarised Retroreflective, AC/DC supply, relay, 10 m cable
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMR79010?
- XCSDMR79010 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMR79010.
- What is the HS code for XCSDMR79010?
- The customs tariff (HS) code for XCSDMR79010 is 8544.42.
- Who manufactures XCSDMR79010?
- XCSDMR79010 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMR79010?
- Yes — the XCSDMR79010 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMR79010?
- The minimum order quantity is 1.
- Is XCSDMR79010 available?
- Yes — XCSDMR79010 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
