Telemecanique XCSDMP590L05M8 Coded Magnetic Safety Switch, 1 NO + 1 NC, 05 m cable
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMP590L05M8 coded magnetic safety interlock switch for guard-door monitoring, 1 NO + 1 NC contacts, 05 m cable.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMP590L05M8
- EAN / GTIN
- 3666916059753
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 50 pcs
- Contact configuration
- NO + NC
- Type of actuation
- Magnet
- Type of electric connection
- Connector M8
- Type of switching output
- Relay contact
- Width sensor
- 25 mm
- Height of sensor
- 88 mm
- Length of sensor
- 13 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3666916059753
- SAP 1000342319
- Code 81106743
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique OsiSense XS506B1PAL2 Inductive Proximity Sensor — Ø6.5 mm barrel, Sn 6.5 mm, PNP, NO, pre-wired cable
Telemecanique
Telemecanique XUB2AKSNL2T Photoelectric Through-Beam Emitter, Plastic, 2 m cable
Telemecanique
Telemecanique XMLR010G1N26 Pressure Sensor with Display, 0–10 bar, 4–20 mA + 1× NPN
Telemecanique
Telemecanique XUB1ANANM12 Photoelectric Sensor M18, Retroreflective, Plastic, NPN, M12 connector
Telemecanique
Telemecanique XCKJ1161H29 Limit Switch, Metal Plunger, M20 entry
Telemecanique
Telemecanique XUB0SKSNM12T Photoelectric Emitter M18, M12 connector
Telemecanique
Telemecanique XMLP3K0PP230 Pressure Transmitter, 0–3000 psi, 0.5–4.5 V ratiometric, 1/4" NPT, Packard connector
Telemecanique
Telemecanique XZCC8FCM30S Field-Wireable Connector, M8, Female, Angled
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMP590L05M8?
- XCSDMP590L05M8 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMP590L05M8.
- What is the HS code for XCSDMP590L05M8?
- The customs tariff (HS) code for XCSDMP590L05M8 is 8536.90.
- Who manufactures XCSDMP590L05M8?
- XCSDMP590L05M8 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMP590L05M8?
- Yes — the XCSDMP590L05M8 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMP590L05M8?
- The minimum order quantity is 1.
- Is XCSDMP590L05M8 available?
- Yes — XCSDMP590L05M8 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
