Telemecanique XMLR010G1N26 Pressure Sensor with Display, 0–10 bar, 4–20 mA + 1× NPN

Telemecanique XMLR010G1N26 OsiSense XMLR electronic pressure sensor with digital display, measuring range 0–10 bar, 4–20 mA + 1× NPN output, G 1/4 A process connection, M12 connector.

Manufacturer part number (MPN)

XMLR010G1N26 EAN / GTIN: 3666916021071 Sales unit: pcs Pressure: 10 bar Output type: NPN Output signal: 4–20 mA Width: 41 mm Height: 100 mm Depth: 42 mm With display: No Number of normally open contacts as main contact: 1 Number of normally closed contacts as main contact: 1 With manual on/off switch: No Initial setting: 0–1000 hPa End setting: 0–1000 hPa Max. operation pressure: 10000 hPa Explosion-proof: No Degree of protection (IP): IP65/IP67 Initial value measuring range pressure: 50000 Pa Switch off pressure: 0.8–10 bar Rated voltage Ue at DC: 24 V Bursting pressure: 40 bar Engaging pressure: 0.5–10 bar Electronic version: Yes End value measuring range pressure: 1000000 Pa Suitable as 2-point controller: No Suitable as limiter: No Suitable as guard: Yes Max. test pressure: 40 bar Medium temperature: -20–80 °C With hand operation: No Pressure-switching differential: 0.3 bar Max. operating pressure: 1000 hPa Country of origin: Switzerland

HS Code

9026.20

• EAN 3666916021071
• SAP 1000632314
• Code 8308106
