Telemecanique XCSDMP50110 Coded Magnetic Safety Switch, 1 NO + 2 NC, with LED
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMP50110 coded magnetic safety interlock switch for guard-door monitoring, 1 NO + 2 NC contacts, with LED.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMP50110
- EAN / GTIN
- 3666916059852
- Sales unit
- pcs
- Package quantity
- 8 pcs
- Contact configuration
- NO + 2 NC
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Width sensor
- 25 mm
- Height of sensor
- 88 mm
- Length of sensor
- 13 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916059852
- SAP 1000342314
- Code 8998999
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XY2CD01 Pull Rope 6 m for Rope Pull Switches
Telemecanique
Telemecanique XUFZ11 Cutting Tool for Optical Fibre
Telemecanique
Telemecanique multifunction voltage control relay RM35-U - range 15..600 V RM35UA13MW
Telemecanique
Telemecanique XY2CJS15H29 Emergency Stop Rope Pull Switch, 20 m Rope Span, 1 NC + 1 NO, M20 entry
Telemecanique
Telemecanique XT230A1FBL2 Capacitive Proximity Sensor Ø30 mm, AC 2-Wire, 2 m cable
Telemecanique
Telemecanique XCKJ10513D Limit Switch, Short Lever with Steel Roller, Metal Body, M12 connector
Telemecanique
Telemecanique XY2CH13190H7 Emergency Stop Rope Pull Switch, 30 m Rope Span, 2 NC + 1 NO, 1/2" NPT entry
Telemecanique
Telemecanique OsiSense XS1N30PB349D Inductive Proximity Sensor — M30 barrel, Sn 20 mm, PNP, NC
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMP50110?
- XCSDMP50110 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMP50110.
- What is the HS code for XCSDMP50110?
- The customs tariff (HS) code for XCSDMP50110 is 8536.50.
- Who manufactures XCSDMP50110?
- XCSDMP50110 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMP50110?
- Yes — the XCSDMP50110 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMP50110?
- The minimum order quantity is 1.
- Is XCSDMP50110 available?
- Yes — XCSDMP50110 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
