Telemecanique XCSDMC7905 Coded Magnetic Safety Switch, 2 NO, 5 m cable
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMC7905 coded magnetic safety interlock switch for guard-door monitoring, 2 NO contacts, 5 m cable.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMC7905
- EAN / GTIN
- 3666916060018
- HS code
- 8544.42
- Sales unit
- pcs
- Package quantity
- 15 pcs
- Contact configuration
- NO + NO
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Width sensor
- 16 mm
- Height of sensor
- 51 mm
- Length of sensor
- 7 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Protected switch distance OFF
- 15 mm
- Protected switch distance ON
- 5 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Ambient temperature
- -25–85 °C
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Rated supply voltage DC
- 24 V
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 15 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8544.42
Cross References
- EAN 3666916060018
- SAP 1000254576
- Code 81136178
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XUSL4E14F121N Safety Light Curtain Type 4, Finger Detection (14 mm), 1210 mm Height
Telemecanique
Telemecanique XUB4BNANL2 Photoelectric Sensor M18, Metal, NPN, 2 m cable
Telemecanique
Telemecanique XCSDMP7905 Coded Magnetic Safety Switch, 2 NC, 5 m cable
Telemecanique
Telemecanique XUK2ARCNL10R Photoelectric Through-Beam Receiver, Plastic, AC/DC Multi-Voltage, Relay Output, 10 m cable
Telemecanique
Limit switch with M12 connector (XCMV2115M12)
Telemecanique
Telemecanique XUSL4E30H031N Safety Light Curtain Type 4, Hand Detection (30 mm), 310 mm Height
Telemecanique
IND.Transmitter 10-30V DC PNP 1NO
XS7G12PA140S
Telemecanique
Telemecanique XCKM521H29 Limit Switch, Plunger, 1 NO + 1 NC, M20 entry
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMC7905?
- XCSDMC7905 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMC7905.
- What is the HS code for XCSDMC7905?
- The customs tariff (HS) code for XCSDMC7905 is 8544.42.
- Who manufactures XCSDMC7905?
- XCSDMC7905 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMC7905?
- Yes — the XCSDMC7905 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMC7905?
- The minimum order quantity is 1.
- Is XCSDMC7905 available?
- Yes — XCSDMC7905 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
