Telemecanique XCSLE3737342 Safety Interlock Switch, 230 V Solenoid, 2NO+2NC

Telemecanique XCSLE3737342 is a mechanical safety interlock switch in a plastic housing with a 230 V AC/DC solenoid guard lock on the operating current principle. Contact block provides 2 NO and 2 NC slow-action contacts, rated 0.75 A AC-15 at 230 V and 0.55 A DC-13 at 24 V. Sensor dimensions are 205 mm high by 51 mm long by 44 mm wide, with metric cable entry and IP67K protection over -25 to 60 degC. Guard locking force is 20 N. Country of origin is Indonesia.

Manufacturer part number (MPN)

XCSLE3737342

EAN / GTIN

3666916047927

Sales unit

pcs

Package quantity

8 pcs

Voltage

230 V

Contact configuration

2 NO

Type of locking

Operating current principle

Rated operation current Ie at AC-15, 230 V

0.75 A

Housing material

Plastic

Suitable for safety functions

Yes

With status indication

Yes

Type of switching contact

Slow-action switch

Type of interface for safety communication

None

Type of electric connection

Cable entry metrical

Explosion safety category for gas

None

Degree of protection (IP)

IP67K

Type of interface

None

Rated control supply voltage magnet drive AC 50 Hz

230 V

Rated control supply voltage magnet drive AC 60 Hz

230 V

Rated control supply voltage magnet drive DC

230 V

Rated operation current Ie at DC-13, 24 V

0.55 A

Width sensor

44 mm

With escape release

No

Height of sensor

205 mm

Length of sensor

51 mm

Ambient temperature during operating

-25–60 °C

Guard locking force

20 N

Number of contacts as normally closed contact

2

Number of contacts as normally open contact

1

With auxiliary release

No

Type of guard locking

Quiescent current principle

Country of origin

Indonesia

HS Code

8536.50
