Telemecanique XCSDMP59110 Coded Magnetic Safety Switch, 2 NC, with LED
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMP59110 coded magnetic safety interlock switch for guard-door monitoring, 2 NC contacts, with LED.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMP59110
- EAN / GTIN
- 3666916059746
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 8 pcs
- Contact configuration
- NC + NC
- Number of protected contact energized outputs
- 2
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Width sensor
- 25 mm
- Height of sensor
- 88 mm
- Length of sensor
- 13 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3666916059746
- SAP 1000342320
- Code 81106744
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XZCP1164L5 Sensor Cable, M12 female straight, 5-pin, 5 m
Telemecanique
Telemecanique XUSL4E14F061NWH Safety Light Curtain Type 4, Finger Detection (14 mm), 610 mm Height
Telemecanique
Telemecanique XSAV11373TFEX Rotation Monitor (Under-Speed Detector) M30, 12–48 V, Ex Version
Telemecanique
Telemecanique XUYFALNEP60030 Laser Fork Sensor 59 × 30 mm, Teach-In, M8 Connector
Telemecanique
Telemecanique XZCR1511040A1 Sensor Cable, M12 to M12
Telemecanique
Telemecanique OsiSense XS1N18PA349L1 Inductive Proximity Sensor — M18 barrel, Sn 10 mm, PNP, NO, pre-wired cable
Telemecanique
Bracket with Angle F/XX630/930
XXZ30
Telemecanique
Telemecanique XS118B3PAM12 Inductive Proximity Sensor Ø18 mm, Threaded, PNP NO, M12 connector
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMP59110?
- XCSDMP59110 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMP59110.
- What is the HS code for XCSDMP59110?
- The customs tariff (HS) code for XCSDMP59110 is 8536.90.
- Who manufactures XCSDMP59110?
- XCSDMP59110 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMP59110?
- Yes — the XCSDMP59110 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMP59110?
- The minimum order quantity is 1.
- Is XCSDMP59110 available?
- Yes — XCSDMP59110 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
