Telemecanique XX218A3PFM12 Ultrasonic Sensor, Sn 0.5 m, PNP, M12 connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XX218A3PFM12 OsiSense XX ultrasonic proximity sensor, Sn 0.5 m, PNP output, M12 connector.
Technical Specifications
- Manufacturer part number (MPN)
- XX218A3PFM12
- EAN / GTIN
- 3666916080009
- Sales unit
- pcs
- Package quantity
- 15 pcs
- Diameter
- 18 mm
- Output type
- PNP
- Nominal sensing distance Sn
- 0.5 m
- Voltage type
- AC/DC
- Max. output current
- 100 mA
- Housing material
- Plastic
- Ambient temperature
- -20–65 °C
- Switching frequency
- 300000 Hz
- Type of electric connection
- Connector M12
- Type of switching output
- PNP/PNP
- Type of switch function
- Normally open contact (NO)
- Blind zone
- 51 mm
- Setting procedure
- Teach-In
- Explosion safety category for gas
- None
- Construction type housing
- Cylinder, screw-thread
- No-load current
- 40 mA
- Relative linearity deflection
- 0 %
- Relative repeat accuracy
- 1.27 %
- Synchronisation possible
- No
- Supply voltage
- 12–24 V
- Material active area of sensor
- Plastic
- Degree of protection (IP)
- IP67
- Width sensor
- 18 mm
- Diameter sensor
- 18 mm
- Height of sensor
- 18 mm
- Length of sensor
- 79 mm
- Adjustable distance
- 51–508 mm
- Measuring range length
- 51–508 mm
- Country of origin
- United States
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916080009
- SAP 1000073519
- Code 8776657
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XZCPV0566L2 Sensor Cable, M8 female, 3-pin, PVC, 2 m
Telemecanique
Telemecanique XCKN2110P20 Limit Switch, Plunger, NC+NO, Plastic Body, M20 cable entry
Telemecanique
Telemecanique XS130B3PBM12 Inductive Proximity Sensor Ø30 mm, Threaded, PNP NC, M12 connector
Telemecanique
Telemecanique XZCR1510040H2 Sensor Cable, M12 to M12
Telemecanique
Telemecanique XUSL4E3BB081NM Safety Light Grid Type 4, Body Detection, 3 Beams, 810 mm
Telemecanique
Telemecanique XMEP100BD11F Pressure Transmitter, 0–100 bar, G 1/4 A, 0.5–4.5 V ratiometric
Telemecanique
Telemecanique XXV18B1NBL5 Ultrasonic Sensor M18, Metal, NPN, NC, Range 5 m, 5 m cable
Telemecanique
Telemecanique OsiSense XS630B1PBL2 Inductive Proximity Sensor — M30 barrel, Sn 15 mm, PNP, NC, pre-wired cable
