Telemecanique XMLB002A2S12 Pressure Switch, 0–2.5 bar
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XMLB002A2S12 OsiSense XMLB electromechanical pressure switch, adjustable range 0–2.5 bar.
Technical Specifications
- Manufacturer part number (MPN)
- XMLB002A2S12 EAN / GTIN: 3666916025383 Sales unit: pcs Pressure: 0.3-2.5 bar Measuring range: 0.3–2.5 bar Width: 55 mm Height: 113 mm Depth: 75 mm With display: No With manual on/off switch: No Initial setting: 300–2500 hPa End setting: 140–2290 hPa Max. operation pressure: 5000 hPa Number of auxiliary contacts as change-over contact: 1 Type of electric connection: Screw connection Explosion-proof: No Degree of protection (IP): IP66 Switch off pressure: 0.14–2.29 bar Rated voltage Ue at AC 50 Hz: 120–240 V Rated voltage Ue at AC 60 Hz: 120–240 V Rated voltage Ue at DC: 250 V Bursting pressure: 18 bar Engaging pressure: 0.3–2.5 bar Electronic version: No Suitable as 2-point controller: Yes Suitable as limiter: Yes Suitable as guard: Yes Max. test pressure: 9 bar Medium temperature: 0–70 °C With hand operation: No Pressure-switching differential: 1.54 bar Max. operating pressure: 2500 hPa Country of origin: France
Standards & Compliance
- HS Code
- 9032.20
Cross References
- EAN 3666916025383
- SAP 1000341836
- Code 81106505
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XZCP1440L5 Sensor Cable, M12 female angled, 3-pin, 5 m
Telemecanique
Telemecanique XX512A1KAM8 Ultrasonic Sensor, Sn 6 m, PNP + NPN, M8 connector
Telemecanique
Telemecanique ZCMD37L1 Limit Switch Body, Metal, NC/NC/NO, Slow-break, 1 m cable
Telemecanique
Telemecanique XZCR2705037R2 Sensor Cable, M8 to M8, 2 m
Telemecanique
Telemecanique OsiSense XS530BLPAL2 Inductive Proximity Sensor — M30 barrel, Sn 10 mm, PNP, NO, pre-wired cable (2 m)
Telemecanique
Telemecanique OsiSense XS8C2A4DAM12 Inductive Proximity Sensor — 40 × 40 × 70 mm block, Sn 40 mm, 2-Wire DC, NO, M12 connector (4-Pin)
Telemecanique
Telemecanique ZCKD05 Operating Head for ZCK Limit Switches
Telemecanique
Telemecanique XMEP060BV71F Pressure Transmitter, G 1/4 A, 0.5–4.5 V ratiometric, AMP connector
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XMLB002A2S12?
- XMLB002A2S12 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XMLB002A2S12.
- What is the HS code for XMLB002A2S12?
- The customs tariff (HS) code for XMLB002A2S12 is 9032.20.
- Who manufactures XMLB002A2S12?
- XMLB002A2S12 is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for XMLB002A2S12?
- Yes — the XMLB002A2S12 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XMLB002A2S12?
- The minimum order quantity is 1.
- Is XMLB002A2S12 available?
- Yes — XMLB002A2S12 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
