Telemecanique XMLA160D2C11 Pressure Switch, 10–160 bar, DIN connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XMLA160D2C11 OsiSense XMLA electromechanical pressure switch, adjustable range 10–160 bar, DIN connector.
Technical Specifications
- Manufacturer part number (MPN)
- XMLA160D2C11 EAN / GTIN: 3666916025666 Sales unit: pcs Package quantity: 13 pcs Pressure: 10-160 bar Width: 35 mm Height: 113 mm Depth: 75 mm Connection: Internal thread cylindrical BSPP-G (ISO 228-1) With display: No With manual on/off switch: No Initial setting: 10000–160000 hPa End setting: 4500–142000 hPa Max. operation pressure: 200000 hPa Number of auxiliary contacts as change-over contact: 1 Explosion-proof: No Degree of protection (IP): IP65 Switch off pressure: 4.5–142 bar Rated voltage Ue at AC 50 Hz: 120–240 V Rated voltage Ue at AC 60 Hz: 120–240 V Rated voltage Ue at DC: 250 V Bursting pressure: 720 bar Engaging pressure: 10–160 bar Electronic version: No Suitable as 2-point controller: No Suitable as limiter: Yes Suitable as guard: Yes Max. test pressure: 360 bar Medium temperature: 0–160 °C With hand operation: No Pressure-switching differential: 18 bar Max. operating pressure: 160000 hPa Country of origin: Czechia
Standards & Compliance
- HS Code
- 9032.20
Cross References
- EAN 3666916025666
- SAP 1000257340
- Code 8231046
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique OsiSense XS1M30MA250 Inductive Proximity Sensor — M30 barrel, Sn 10 mm, 2-Wire AC/DC, NO, pre-wired cable (2 m)
Telemecanique
Telemecanique XMXA25L2135 Pressure Switch 3.5–25 bar, Internally Adjustable, Black Cover
Telemecanique
Telemecanique XMLG006D21 Pressure Transmitter, 0–6 bar, 4–20 mA
Telemecanique
Telemecanique XXS18P1VM12 Ultrasonic Sensor, M18, Sn 1 m, 0–10 V, M12 connector
Telemecanique
Telemecanique OsiSense XS218B4PBL2 Inductive Proximity Sensor — M18 barrel, Sn 16 mm, PNP, NC, pre-wired cable (2 m)
Telemecanique
Telemecanique multifunction control relay RM17-TT - range 183..528 V AC RM17TT00
Telemecanique
Telemecanique ZCKY101 Slide Bolt with Actuator Key for Safety Switches
Telemecanique
Telemecanique XUSL4E30H061NS1 Safety Light Curtain Type 4, Hand Detection (30 mm), 610 mm Height
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XMLA160D2C11?
- XMLA160D2C11 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XMLA160D2C11.
- What is the HS code for XMLA160D2C11?
- The customs tariff (HS) code for XMLA160D2C11 is 9032.20.
- Who manufactures XMLA160D2C11?
- XMLA160D2C11 is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for XMLA160D2C11?
- Yes — the XMLA160D2C11 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XMLA160D2C11?
- The minimum order quantity is 1.
- Is XMLA160D2C11 available?
- Yes — XMLA160D2C11 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
