Product Description
SKF NU-2310-ECP Single-row cylindrical roller 50×110×40mm, wide-inner-ring, polyamide cage. High radial load + high speed.
Technical Specifications
- Part
- NU-2310-ECP
- Type
- Cylindrical roller
- Tolerance
- P6 standard (tighter P5/P4 on request)
- Cage
- Steel (standard) / polyamide / brass / ceramic (special)
- Seal
- 2RSH double contact seal (for -2RSH codes)
- Lube
- SKF LGMT 2 / LGEP 2 / LGWA 2 (application-dep)
- Bore diameter
- 50 mm
- Outside diameter
- 110 mm
- Width
- 40 mm
- Basic dynamic load rating
- 186 kN
- Basic static load rating
- 186 kN
- Reference speed
- 6700 r/min
- Limiting speed
- 8000 r/min
- SKF performance class
- SKF Explorer
- Bearing part
- Complete bearing
- Axial displacement capability
- In both directions
- Number of rows
- 1
- Locating feature, bearing outer ring
- Without
- Bore type
- Cylindrical
- Number of flanges, outer ring
- 2
- Radial internal clearance
- CN
- Tolerance class
- Normal
- Coating
- Without
- Sealing
- Without
- Relubrication feature
- Without
- Indicative carbon footprint for new product
- 6.4 kg CO2e
- Product net weight
- 1.73 kg
- eClass code
- 23-05-09-01
- UNSPSC code
- 31171505
- Loose flange
- None
Standards & Compliance
- Classification / Approval
- ISO 492 tolerance / ISO 281 life rating
- HS Code
- 8482.10
Compatibility & Fitment
Interchangeable with equivalent FAG / NSK / NTN / Timken part numbers at same ISO designation.
