Product Description
SKF Y-bearing flanged housing unit, 35mm shaft, ZN setscrew lock, cast-iron flange. Conveyor + fan shaft.
Technical Specifications
- Part
- FY-35-TF
- Type
- Flanged unit
- Tolerance
- P6 standard (tighter P5/P4 on request)
- Cage
- Steel (standard) / polyamide / brass / ceramic (special)
- Seal
- 2RSH double contact seal (for -2RSH codes)
- Lube
- SKF LGMT 2 / LGEP 2 / LGWA 2 (application-dep)
- Shaft diameter
- 35 mm
- Housing overall width
- 34.5 mm
- Width, total
- 46.4 mm
- Centre distance between bolt holes
- 92 mm
- Bearing width, total
- 42.9 mm
- Attachment bolt diameter
- 12 mm
- Basic dynamic load rating
- 25.5 kN
- Basic static load rating
- 15.3 kN
- Limiting speed
- 5300 r/min
- Note
- Limiting speed with shaft tolerance h6
- Housing type
- Flanged
- Flanged housing type
- Square
- Number of bolt holes for fasteners
- 4
- Fastening bolt hole type
- Plain
- Retaining feature, inner ring
- Set screws
- Bore type
- Cylindrical
- Rubber seating ring
- Without
- Material, housing
- Cast iron
- Material, bearing
- Bearing steel
- Coating
- Without
- Sealing, bearing
- Seal and flinger on both sides
- Sealing type
- Contact, standard
- Sealing, unit
- Optional end cover
- Lubricant
- Grease
- Relubrication hole
- With
- Grease fitting
- With
- Unit system
- Metric
- Product net weight
- 1.31 kg
- eClass code
- 23-05-08-02
- UNSPSC code
- 31171536
Standards & Compliance
- Classification / Approval
- ISO 492 tolerance / ISO 281 life rating
- HS Code
- 8482.10
Compatibility & Fitment
Interchangeable with equivalent FAG / NSK / NTN / Timken part numbers at same ISO designation.
