Siemens SIMATIC S7-1500 AQ 8XU/I HS

Siemens 6ES7532-5HF00-0AB0 — SIMATIC S7 automation module. Compact controller or expansion module for the S7-1200 or S7-1500 PLC platform. Simatic S7 1500 AQ 8 X U/In/ST, 8 channels in group on 8.

Manufacturer part number (MPN)

6ES7532-5HF00-0AB0

EAN / GTIN

4025515080176

Sales unit

pcs

Product type designation

AQ 8xU/I HS

HW functional status

from FS01

Firmware version

V2.1.0

Product function — I&M data

Yes; I&M0 to I&M3

Engineering with — STEP 7 TIA Portal configurable/integrated from version

V14 / -

Engineering with — STEP 7 configurable/integrated from version

V5.5 SP3 / -

Engineering with — PROFIBUS from GSD version/GSD revision

V1.0 / V5.1

Engineering with — PROFINET from GSD version/GSD revision

V2.3 / -

Rated value (DC)

24 V

Permissible range, lower limit (DC)

19.2 V

Permissible range, upper limit (DC)

28.8 V

Current consumption, max.

320 mA; with 19.2 V supply

Power consumption from the backplane bus

1.15 W

Power loss, typ.

7 W

Number of analog outputs

8

Voltage output, short-circuit current, max.

45 mA

Current output, no-load voltage, max.

20 V

Cycle time (all channels), min.

125 µs; independent of number of activated channels

Analog output with oversampling — Values per cycle, max.

16

Analog output with oversampling — Resolution, min.

125 µs

Load impedance (in rated range of output) — with voltage outputs, min.

1 kΩ

Load impedance (in rated range of output) — with voltage outputs, capacitive load, max.

100 nF

Load impedance (in rated range of output) — with current outputs, max.

500 Ω

Load impedance (in rated range of output) — with current outputs, inductive load, max.

1 mH

Cable length — shielded, max.

200 m

Integration and conversion time/resolution per channel — Resolution with overrange (bit including sign), max.

16 bit

Integration and conversion time/resolution per channel — Conversion time (per channel)

50 µs; independent of number of activated channels

Settling time — for resistive load

30 µs; see additional description in the manual

Settling time — for capacitive load

100 µs; see additional description in the manual

Settling time — for inductive load

100 µs; see additional description in the manual

Output ripple (relative to output range, bandwidth 0 to 50 kHz), (+/-)

0.02 %

Linearity error (relative to output range), (+/-)

0.15 %

Temperature error (relative to output range), (+/-)

0.002 %/K

Crosstalk between the outputs, max.

-100 dB

Repeat accuracy in steady state at 25 °C (relative to output range), (+/-)

0.05 %

Note regarding accuracy

at temperatures below 0 °C, the figures for operating error and temperature error are doubled

Operational error limit in overall temperature range — Voltage, relative to output range, (+/-)

0.3 %

Operational error limit in overall temperature range — Current, relative to output range, (+/-)

0.3 %

Basic error limit (operational limit at 25 °C) — Voltage, relative to output range, (+/-)

0.2 %

Basic error limit (operational limit at 25 °C) — Current, relative to output range, (+/-)

0.2 %

Execution and activation time (TCO), min.

100 µs

Bus cycle time (TDP), min.

250 µs

Diagnostics indication LED — Monitoring of the supply voltage (PWR-LED)

Yes; green LED

Potential separation channels — between the channels, in groups of

8

Between S- and MANA (UCM)

8 V DC

Isolation tested with

707 V DC (type test)

Suitable for safety-related tripping of standard modules

Yes; from FS04

Highest safety class achievable for safety-related tripping of standard modules — Category according to ISO 13849-1

Cat. 3

Highest safety class achievable for safety-related tripping of standard modules — SIL acc. to IEC 62061

SIL 2

Highest safety class achievable for safety-related tripping of standard modules — remark on safety-oriented shutdown

https://support.industry.siemens.com/cs/de/en/view/39198632

Ambient temperature during operation — horizontal installation, min.

-30 °C; From FS03

Ambient temperature during operation — horizontal installation, max.

60 °C

Ambient temperature during operation — vertical installation, min.

-30 °C; From FS03

Ambient temperature during operation — vertical installation, max.

40 °C

Altitude during operation relating to sea level — Installation altitude above sea level, max.

5 000 m; Restrictions for installation altitudes > 2 000 m, see manual

Absolute humidity — dew point, min.

-60 °C; suitable for dry room applications

Dimensions — Width

35 mm

Dimensions — Height

147 mm

Dimensions — Depth

129 mm

Weight, approx.

325 g

Number of analogue outputs

8

Analogue inputs configurable

No

Input, current

No

Input, voltage

No

Input, resistor

No

Input, resistance thermometer

No

Input, thermocouple

No

Input signal, configurable

No

Resolution of the analogue outputs

16 Bit

Explosion safety category for gas

ATEX gas-ex-protection, Cat. 3G

Explosion safety category for dust

None

Width

35 mm

Height

147 mm

Depth

129 mm

Country of origin

Germany

HS Code

8538.90
