Siemens SITOP DC power supply 6EP1961-3BA01

Siemens 6EP1961-3BA01 — SITOP DC power supply. DIN-rail primary-switched regulated 24 VDC power supply for automation panels. SITOP, Buffermodul for 6EP1X3X-3BAX0, buffertkapasitet 100ms/40A, 200ms/20 A.

Manufacturer part number (MPN)

6EP1961-3BA01

EAN / GTIN

4025515152576

Sales unit

pcs

Supply voltage at DC rated value

24 V

Input voltage at DC

24 ... 28.8 V

Design of the mains power cut bridging-connection

Backup time: with 40 A load current: 200 ms; with 20 A load current: 400 ms; with 10 A load current: 800 ms; with 5 A load current: 1.6 s. Reduces the backup time by 100 ms in combination with 6EP1 437-3BA10. Maximum backup time 100 ms i...

Buffering time in the event of power failure

0.16 min

Formula for output voltage

Vin - approx. 1 V

Output current — rated value

40 A

Display version — for normal operation

Green LED for "supply voltage > 20.5 V"

Product component PC interface

No

Product function communication function

No

Design of the interface

without

Galvanic isolation between input and output

Yes

Operating resource protection class

Class III

Protection class IP

IP20

Standard — for emitted interference

EN 55022 Class B

Standard — for interference immunity

EN 61000-6-2

Shipbuilding approval

Yes

Ambient temperature — during operation

-25 ... +70 °C; with natural convection

Ambient temperature — during transport

-40 ... +85 °C

Ambient temperature — during storage

-40 ... +85 °C

Type of electrical connection

screw terminal

Connection method — at input

+: 1 screw terminal for 0.5 ... 10 mm²

Connection method — at output

-: 1 screw terminal for 0.5 ... 10 mm²

Width × height × depth of the enclosure

70 × 125 × 121 mm

Installation width × mounting height

70 mm × 225 mm

Fastening method

Snaps onto DIN rail EN 60715 35x7.5/15

Housing can be lined up

Yes

Mechanical data — net weight

1.2 kg

Country of origin

Germany

HS Code

8504.90

• EAN 4025515152576
• SAP 1000350932
• Code 81127669
