Siemens SIMATIC, electronic module for ET200ISP, 4 AI, TC: for connection of thermocouples (voltage measurement)

Siemens 6ES7134-7SD00-0AB0 — SIMATIC S7 automation module. Compact controller or expansion module for the S7-1200 or S7-1500 PLC platform. SIMATIC ET 200iSP 4AI TC.

Manufacturer part number (MPN)

6ES7134-7SD00-0AB0

EAN / GTIN

4019169132077

Sales unit

pcs

Product type designation

4AI TC

HW functional status

7

Firmware version

V1.0.1

Permissible range, lower limit (DC)

20.4 V

Permissible range, upper limit (DC)

28.8 V

Current consumption, typ.

17 mA

From load voltage (power bus), max.

30 mA

Power loss, typ.

0.4 W

Number of analog inputs

4

Cycle time (all channels) max.

320 ms; 66 ms basic conversion time x 4 channels with interference frequency suppression 60 Hz, 80 ms basic conversion time x 4 channels with interference frequency suppression 50 Hz

Input ranges (rated values), voltages — Input resistance (-80 mV to +80 mV)

1 000 kΩ

Input ranges (rated values), thermocouples — Input resistance (Type B)

1 000 kΩ

Input ranges (rated values), thermocouples — Input resistance (Type C)

1 000 kΩ

Input ranges (rated values), thermocouples — Input resistance (Type E)

1 000 kΩ

Input ranges (rated values), thermocouples — Input resistance (type J)

1 000 kΩ

Input ranges (rated values), thermocouples — Input resistance (Type K)

1 000 kΩ

Input ranges (rated values), thermocouples — Input resistance (Type L)

1 000 kΩ

Input ranges (rated values), thermocouples — Input resistance (Type N)

1 000 kΩ

Input ranges (rated values), thermocouples — Input resistance (Type R)

1 000 kΩ

Input ranges (rated values), thermocouples — Input resistance (Type S)

1 000 kΩ

Input ranges (rated values), thermocouples — Input resistance (Type T)

1 000 kΩ

Input ranges (rated values), thermocouples — Input resistance (Type U)

1 000 kΩ

Temperature compensation — external temperature compensation with compensations socket

Yes; via temperature value, acquired by an analog module of the same ET 200iSP station

Cable length — shielded, max.

50 m

Integration and conversion time/resolution per channel — Resolution with overrange (bit including sign), max.

16 bit

Integration and conversion time/resolution per channel — Basic conversion time, including integration time (ms)

80 ms at 50 Hz; 66 ms at 60 Hz

Integration and conversion time/resolution per channel — additional conversion time for wire-break monitoring

5 ms

Smoothing of measured values — Parameterizable

Yes; in 4 stages

Smoothing of measured values — Step

None: Yes; 1x cycle time

Linearity error (relative to input range), (+/-)

0.015 %

Temperature error (relative to input range), (+/-)

0.02 %/K

Crosstalk between the inputs, min.

-50 dB

Repeat accuracy in steady state at 25 °C (relative to input range), (+/-)

0.01 %

Operational error limit in overall temperature range — Voltage, relative to input range, (+/-)

0.15 %

Basic error limit (operational limit at 25 °C) — Voltage, relative to input range, (+/-)

0.1 %

Interference voltage suppression for f = n x (f1 +/- 1 %), f1 = interference frequency — Common mode interference, min.

90 dB

Number of PROFINET interfaces

0

Diagnoses — Wire break

Yes; R > 1.7 kOhm

Module for Ex(i) protection

Yes; for more Co/Lo combinations, see certificate IECEx KEM 05.0008

Maximum values for connecting terminals for gas group IIC — Uo (no-load voltage), max.

5.9 V

Maximum values for connecting terminals for gas group IIC — Io (short-circuit current), max.

15 mA

Maximum values for connecting terminals for gas group IIC — Po (power output), max.

23 mW

Maximum values for connecting terminals for gas group IIC — Co (permissible external capacity), max.

43 µF

Maximum values for connecting terminals for gas group IIC — Lo (permissible external inductivity), max.

100 mH

IP degree of protection

IP30

CE mark

CE 0344

UKCA mark

DEKRA 21UKEX0086 Importer UK: Siemens plc Manchester M20 2UR

CULus

LISTED E334384

FM approval

CLASSIFIED 3025852

INMETRO certificate

UL-BR 12.0071

Use in hazardous areas — ATEX marking

II 2 G (1) G Ex ib [ia Ga] IIC T4 Gb II 2 G (1) D Ex ib [ia IIIC Da] IIC T4 Gb I M2 Ex ib [ia] I Mb

Use in hazardous areas — Explosion protection category for gas

ATEX gas explosion protection, Zone 1

Use in hazardous areas — Explosion protection category for dust

ATEX dust explosion protection, Zone 21 always install in corresponding enclosure

Dimensions — Width

30 mm

Dimensions — Height

129 mm

Dimensions — Depth

136.5 mm

Weight, approx.

230 g

Voltage type (supply voltage)

DC

Resolution of the analogue inputs

16 Bit

Number of analogue inputs

4

Degree of protection (IP)

IP30

Type of electric connection

Screw-/spring clamp connection

SIL according to IEC 61508

None

Performance level according to EN ISO 13849-1

None

Explosion safety category for gas

ATEX gas-ex-protection, Cat. 2G

Explosion safety category for dust

ATEX dust-ex-protection, Cat. 2D

Width

30 mm

Height

129 mm

Depth

136.5 mm

Country of origin

Germany

HS Code

8538.90
